Figure 5: Louroe Audio Monitoring System View
For current specifications and instructions, please see Louroe Support.
The microphone system consists of the following components:
Figure 6: Microphone Components View
Table 2: Microphone Components Description
Item Description
A Microphone
B Audio Interface Adaptor
C Shielded Cable (stripped; not included)
D Power Adaptor
E RCA Cable (one end cut and stripped)
MN010550A01-A
Chapter 3: Interview Room Hardware Component Details
13
