Motorola 3.5

5 Accessory Connector
6 Home Button
7 4–Way Navigation Button
8 Battery Latch
9 Keypad
10 Data Feature Button
11 Menu Select Buttons
12 Main Display
13 2–Position Concentric Switch
1
14 3–Position A/B/C Switch
1
15 On/Off/Volume Control Knob
16 Top Side (Select) Button
1
17 Push-to-Talk (PTT) Button
18 Side Button 1
1
19 Side Button 2
1
20 Battery
21 Bluetooth Pairing Location Indicator
22 Main Speaker
23 Microphone
24 Top Display
25 16–Position Select Knob
1
Programmable Features
Any reference in this manual to controls that are
preprogrammed means that a qualified radio technician
must use the radio programming software to assign a
feature to a control.
Your dealer can program the programmable buttons as
shortcuts to radio functions or preset channels/groups
depending on the duration of a button press:
Press
Pressing and releasing rapidly.
Long press
Pressing and holding for the preprogrammed duration
(between 0.25 and 3.75 seconds).
Hold down
Keeping the button pressed.
1
These radio controls/buttons are programmable.
