Motorola ASTRO SPECTRA User Manual

6881086C22-B 81
C532 2113741B69 CAP CHIP CL2 X7R REEL
100000
C533 2113740A79 CAP CHIP REEL CL1 +/-30
1000
C534 2113740A65 CAP CHIP REEL CL1 +/-30 270
C535 2311049A14 CAP TANT CHIP 4.7 1020 A/P
C536 2113741B69 CAP CHIP CL2 X7R REEL
100000
C537 2113740A79 CAP CHIP REEL CL1 +/-30
1000
C538 2113741B69 CAP CHIP CL2 X7R REEL
100000
C539 2113740A55 CAP CHIP REEL CL1 +/-30 100
C540 2113741A51 CAP CHIP CL2 X7R REEL
18000
C541 2113740A79 CAP CHIP REEL CL1 +/-30
1000
C542 2311049A21 CAP TANT CHIP 22 10 20 A/P
C543 2113740A65 CAP CHIP REEL CL1 +/-30 270
C544 2311049A07 CAP TANT CHIP 1 10 16 A/P
C545 2113741B69 CAP CHIP CL2 X7R REEL
100000
C546 2113741B69 CAP CHIP CL2 X7R REEL
100000
C547 2113741B69 CAP CHIP CL2 X7R REEL
100000
C548 2113741A13 CAP CHIP CL2 X7R REEL 470
C549 2113741A13 CAP CHIP CL2 X7R REEL 470
C550 2113741A13 CAP CHIP CL2 X7R REEL 470
C551 2113741A13 CAP CHIP CL2 X7R REEL 470
C552 2113741A13 CAP CHIP CL2 X7R REEL 470
C553 2113741A13 CAP CHIP CL2 X7R REEL 470
C554 2113741A13 CAP CHIP CL2 X7R REEL 470
C555 2113741A13 CAP CHIP CL2 X7R REEL 470
C556 2113741A13 CAP CHIP CL2 X7R REEL 470
C557 2113741A13 CAP CHIP CL2 X7R REEL 470
C558 2113741A13 CAP CHIP CL2 X7R REEL 470
C559 2113741B69 CAP CHIP CL2 X7R REEL
100000
C560 2113741B69 CAP CHIP CL2 X7R REEL
100000
C561 2113741B69 CAP CHIP CL2 X7R REEL
100000
Ref. Des. Part Number Description
C562 2113741B69 CAP CHIP CL2 X7R REEL
100000
C563 2311049A19 CAP TANT CHIP 10 10 25 A/P
C564 2113741A13 CAP CHIP CL2 X7R REEL 470
C565 2113741A13 CAP CHIP CL2 X7R REEL 470
C566 2113741B69 CAP CHIP CL2 X7R REEL
100000
C601 2113740A55 CAP CHIP REEL CL1 +/-30 100
C602 2113740A55 CAP CHIP REEL CL1 +/-30 100
C603 2311049A03 CAP TANT CHIP A/P .22 10 35
C604 2311049A14 CAP TANT CHIP 4.7 1020 A/P
C605 2113741A49 CAP CHIP CL2 X7R REEL
15000
C606 2311049A19 CAP TANT CHIP 10 10 25 A/P
C607 2113741B69 CAP CHIP CL2 X7R REEL
100000
C608 2113741B69 CAP CHIP CL2 X7R REEL
100000
C615 2113741B69 CAP CHIP CL2 X7R REEL
100000
C651 2113741B69 CAP CHIP CL2 X7R REEL
100000
D1005 4813833C10 DIODE GEN PUR 70V
MMBD6050
D1007 4813833C10 DIODE GEN PUR 70V
MMBD6050
D1008 4813833C10 DIODE GEN PUR 70V
MMBD6050
D1012 4813833C10 DIODE GEN PUR 70V
MMBD6050
D1013 4813833C10 DIODE GEN PUR 70V
MMBD6050
D1017 4813833C10 DIODE GEN PUR 70V
MMBD6050
D1018 4813833C10 DIODE GEN PUR 70V
MMBD6050
D103 4813825A05 DIODE 30V HOT CARRIER
MMBD301L
E1 8083545L04 SPKGAP 3P-4L1
E2 8083545L04 SPKGAP 3P-4L1
HY1 TFN6061A HYBRID FLTR BANDPASS
2175
HY2 TFN6056A HYBRID FLTR NOTCH 2175
J1 2882505T15 CONN HEADER 50 PIN
Ref. Des. Part Number Description
J11 2880004T02 HDR .156 FLK SNPB SR ST 2
POS
J13 0960113B01 JACK MOD. 8 PIN MT
J14 2880068M01 HEADER MIC
J2 2882505T04 PLUG HEADER 34 CKT
J3 2882505T15 CONN HEADER 50 PIN
J4 2884324M07 PLUG HDR 2.54MM GLD ST
SR 2POS
J5 2884324M08 PLUG HDR 2.54MM GLD ST
SR 3POS
J6 2884324M09 PLUG HDR 2.54MM GLD ST
SR 4POS
J8 2884324M08 PLUG HDR 2.54MM GLD ST
SR 3POS
JU100 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
JU101 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
L101 2480289M16 COIL IF 22UH 1611 CS 223
L300 2411087B36 COIL CHIP 6.8 UH 5 A/I
L301 2411087B36 COIL CHIP 6.8 UH 5 A/I
P101 2880001R03 CON PCB HDR .1 GLD SR ST 3
POS
P102 2880001R03 CON PCB HDR .1 GLD SR ST 3
POS
Q101 4813824A10 TSTR NPN 40V .2A GEN PURP
Q102 4813824A10 TSTR NPN 40V .2A GEN PURP
Q110 4813823A08 XSTR P-CH FET SW
MMBFJ175LT1
Q111 4813824A18 XSTR PNP 40V .6A SW B=100
Q113 4884581T01 FET GENPUR N-CH _5459_ 6D
SOT
Q114 4813822A07 TSTR NPN 300V .5A
MJD340T4
Q115 4813822A07 TSTR NPN 300V .5A
MJD340T4
Q116 4813824A10 TSTR NPN 40V .2A GEN PURP
Q117 4813824A10 TSTR NPN 40V .2A GEN PURP
Q118 4813824A10 TSTR NPN 40V .2A GEN PURP
Q306 4813824A10 TSTR NPN 40V .2A GEN PURP
Q307 4813824A10 TSTR NPN 40V .2A GEN PURP
R101 0662057A73 CHIP RES 10K OHMS 5%
R102 0662057A97 CHIP RES 100K OHMS 5%
Ref. Des. Part Number Description
R103 0662057A97 CHIP RES 100K OHMS 5%
R104 0662057A97 CHIP RES 100K OHMS 5%
R105 0662057A73 CHIP RES 10K OHMS 5%
R106 0660076A93 RES CHIP 68K 5 1/8
R107 0660076A88 RES CHIP 43K 5 1/8
R108 0662057A97 CHIP RES 100K OHMS 5%
R109 0662057A75 CHIP RES 12K OHMS 5%
R110 0662057A97 CHIP RES 100K OHMS 5%
R111 0662057A97 CHIP RES 100K OHMS 5%
R112 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R113 0662057A73 CHIP RES 10K OHMS 5%
R114 0662057A97 CHIP RES 100K OHMS 5%
R115 0662057A97 CHIP RES 100K OHMS 5%
R116 0662057A73 CHIP RES 10K OHMS 5%
R117 0662057A73 CHIP RES 10K OHMS 5%
R118 0662057A73 CHIP RES 10K OHMS 5%
R119 0662057A73 CHIP RES 10K OHMS 5%
R120 0660076A65 RES CHIP 4700 5 1/8
R121 0662057A97 CHIP RES 100K OHMS 5%
R122 0660079V49 RES CHIP 1.M OHM 5 1/8W
200PPM
R123 0662057A73 CHIP RES 10K OHMS 5%
R124 0662057A89 CHIP RES 47K OHMS 5%
R125 0660076A57 RES CHIP 2200 5 1/8
R126 0662057A73 CHIP RES 10K OHMS 5%
R127 0660076A61 RES CHIP 3300 5 1/8
R128 0660076A77 RES CHIP 15K 5 1/8
R129 0660076A71 RES CHIP 8200 5 1/8
R134 0662057A73 CHIP RES 10K OHMS 5%
R135 0611072A31 RES CHIP 180 5 1/4
R137 0660076A77 RES CHIP 15K 5 1/8
R138 0660076A09 RES CHIP 22 5 1/8
R139 0660076A09 RES CHIP 22 5 1/8
R140 0660076A09 RES CHIP 22 5 1/8
R141 0660076A09 RES CHIP 22 5 1/8
R145 0660076A41 RES CHIP 470 5 1/8
R146 0611072A47 RES CHIP 820 5 1/4
R147 0660076A41 RES CHIP 470 5 1/8
Ref. Des. Part Number Description
