Maintenance: Maintenance and Troubleshooting Procedures
6881086C22-B 37
Maintenance and
Troubleshooting
Procedures
Depending upon the environment in which the ASTRO Consolette operates, a
service schedule should be created to periodically clean out the inside of the
Consolette. This will ensure proper air flow within the station at all times.
“Diagrams and Parts Lists” on page 51 provides a listing of Troubleshooting
Charts and Schematics, Boards, and Parts Lists. These diagrams contain
detailed cable connectorization information for each cable in the ASTRO
Spectra/Spectra Plus Consolette. These diagrams should be used in
conjunction with the applicable ASTRO Spectra/Spectra Plus Mobile Service
Manual to efficiently service the Consolette.
The troubleshooting charts assist you in tracing a problem to its source. Start
with the “Consolette Does Not Work Troubleshooting Chart” on page 53 and
you will be directed to the source of the problem. Use other troubleshooting
charts and the applicable ASTRO Spectra/Spectra Plus Service Manual to
further identify the source of the problem.
Recommended Test
Equipment and
Service Aids
Electrical • R2001 Communications System Analyzer or R2600 Service Monitor (or
equivalent)
• R1037 or R1024 Digital Multimeter (or equivalent)
• HP8903 Audio Analyzer (or equivalent)
• HP3552 Transmission Test Set (or equivalent)
• 13.8Vdc, 15A Power Supply (for DC-only operation)
• Radio Service Cable (Motorola PN 3084565T01)
• ASTRO Spectra/Spectra Plus Basic Service Manual (Motorola PN
68P81076C20)
• ASTRO Spectra/Spectra Plus Detailed Service Manual (Motorola PN
68P81076C25)
• Current ASTRO Mobile Customer Programming Software
Mechanical • T10, T15, and T25 Torx™ Drivers
• Straight Blade and Phillips Screwdrivers
• Tuning Tool (Motorola PN 66-84974L01)
• 3/16-inch (4.7625 mm) and 11/32-inch (8.73125 mm) Hex Nut Drivers/
Wrenches
• Needle-nose Pliers
• 3/32-inch (2.38125 mm) Allen Wrench
