ASTRO Spectra Plus Consolette Model Chart
ASTRO Spectra Plus Consolette Model Chart
MODEL OR OPTION NUMBER DESCRIPTION
L04JKH9SW7_ 25-50 W 136-162 MHz with Local Control
L04KKH9SW7_ 25-50 W 146-174 MHz with Local Control
L04QKH9SW7_ 20-40 W 403-433 MHz with Local Control
L04RKH9SW7_ 20-40 W 450-482 MHz with Local Control
L04UJH9SW7_ 35 W 806-869 MHz with Local Control
L04KKH9SW9_ 25-50 W 146-174 MHz with Digital Remote Controller
L04QKH9SW9_ 20-40 W 403-433 MHz with Digital Remote Controller
L04RKH9SW9_ 20-40 W 450-482 MHz with Digital Remote Controller
L04UJH9SW9_ 35 W 806-869 MHz with Digital Remote Controller
L146 Tone Remote Control Option (All Local Control Models)
ITEM NUMBER DESCRIPTION
XXXXXXXXX
HPN4005_ Power Supply, 12 V, 12-Amp
XXXXXXXXX
FRN5358_ Fan
XXXXXXXXX
HLN5558_ Command Board
XXXXXXXXX
HLN6282_ Power Cord, 100 V
XXXXXXXXX
HLN6344_ Interconnect Board
XXXXX
HLN6396_ Control Head Board
XXXXX
HLN6441_ Control Head Display
XXXXX
HLN6801_ Hardware Consolette
XXXXXXXXX
HLN6837_ Vocoder Controller (VOCON) Board
XXXXX
HMN1050_ Desk Microphone
XXXXXXXXX
THN6676_ Housing Assembly
XXXXXXXXX
TKN8676_ Cable Kit
XXXXXXXXXD
TRN7391_ Audio Interface Board (AIB)
XXXXX A
PLN1360_ Tone Remote Control Board
XXXXX
TRN7392_ Control Head Bracket Hardware
XXXXX
TRN7393_ Control Head Interface Board
XXXXX
TRN7394_ Speaker Hardware
XXXXXXXXX
HLN6607_ Front Panel Assembly
XXXXX
HLN6688_ Spare Button Kit
XXXXX
HLN6105_ Spare Button Kit
X XXX
HLN6185_ Remote Control Head Hardware
X XXX
TGN6150_ Blank Control Head Panel
XX X
HLN6060_ Radio Dash Hardware, Mid-Power
XX XX
HLN6073_ Radio Dash Hardware, Mid-Power UHF
X X
HLN6126_ Radio Dash Hardware, Mid-Power TD
XX X
HLN6866_ Transceiver Hardware, VHF
XX XX
HLN6418_ Transceiver Hardware
X X
HLN6613_ Transceiver Hardware, 800
XX X
HLD6022_ PA Board, 50 W, VHF
X X
HLE6049_ PA Board, 40 W, Range 1, UHF
X X
HLE6043_ PA Board, 40 W, Range 3, UHF
X X
HLF6077_ Power Amplifier Board, 35 W, 800 MHz
XX X
HRN6014_ ASTRO RF Board, VHF
XX XX
HRN6020_ ASTRO RF Board, UHF
X X
HRN6019_ ASTRO RF Board, 800 MHz
XX X
HLD4342_ VCO Carrier Board, VHF
X X
HLE6045_ VCO Carrier Board, Range 1, UHF
X X
HLE6000_ VCO Carrier Board, Range 3, UHF
X X
HLF6080_ VCO Carrier Board, 800 MHz
X
HLD6061_ Hybrid VCO Board, Range 1, VHF
X X
HLD6062_ Hybrid VCO Board, Range 2, VHF
X X
HLE6101_ Hybrid VCO Board, Range 1, UHF
X X
HLE6103_ Hybrid VCO Board, Range 3, UHF
X X
HLF6079_ Hybrid VCO Board, 800 MHz
X
HRD6001_ Receiver Board, Front-End, Range 1, VHF
X X
HRD6002_ Receiver Board, Front-End, Range 2, VHF
X X
HRE6001_ Receiver Board, Front-End, Range 1, UHF
X X
HRE6003_ Receiver Board, Front-End, Range 3, UHF
X X
HRF6004_ Receiver Board, Front-End, 800 MHz
Key: X = Item Included, D = Item Deleted, A = Item Added

Motorola ASTRO SPECTRA Specifications

General

Frequency Range	136-174 MHz, 403-470 MHz
Number of Channels	Up to 255
Channel Spacing	12.5 kHz, 20 kHz, 25 kHz
Modulation	FM
Operating Temperature	-22°F to +140°F (-30°C to +60°C)
