Motorola ASTRO SPECTRA User Manual

72 6881086C22-B
R149 0611077A26 RES,10
R150 0611077A26 RES,10
R151 0611077A26 RES,10
R152 0611077A26 RES,10
R153 0611077A26 RES,10
R154 0611077A74 RES,1K
R156 0611072A46 RES,750
R157 0611072A46 RES,750
R158 0611072A46 RES,750
R159 0611072A46 RES,750
R160 0611072A46 RES,750
R161 0611072A46 RES,750
R162 0611072A46 RES,750
R163 0611072A46 RES,750
R164 0611072A46 RES,750
R165 0611072A46 RES,750
R166 0611072A46 RES,750
R167 0611072A46 RES,750
R168 0611072A46 RES,750
R169 0611072A46 RES,750
R170 0611072A46 RES,750
R171 0611072A46 RES,750
R172 0611072A46 RES,750
R173 0611072A46 RES,750
R174 0611072A46 RES,750
R175 0611072A46 RES,750
R176 0611072A46 RES,750
R177 0611072A46 RES,750
R178 0611072A46 RES,750
R179 0611072A46 RES,750
R180 0611072A46 RES,750
R181 0611072A46 RES,750
Ref. Des. Part Number Description
R182 0611072A46 RES,750
R183 0611072A46 RES,750
R184 0611072A46 RES,750
R185 0611072A46 RES,750
R186 0611077A98 RES,10K
R187 0611077B15 RES,47K
R188 0611077A26 RES,10
R189 0611072A46 RES,750
R190 0611072A46 RES,750
R191 0611072A46 RES,750
R192 0611072A46 RES,750
R193 0611072A46 RES,750
R194 0611072A46 RES,750
R195 0611072A46 RES,750
R196 0611072A46 RES,750
R197 0611072A46 RES,750
R198 0611072A46 RES,750
R199 0611072A46 RES,750
R200 0611072A46 RES,750
R201 0611072A46 RES,750
R202 0611072A46 RES,750
R203 0611072A46 RES,750
R204 0611072A46 RES,750
R205 0611072A46 RES,750
R210 0611077B23 RES,100K
R211 0611077A26 RES,10
R212 0611077A68 RES,560
R213 0611077A74 RES,1K
R214 0611077B05 RES,18K
R215 0611077B23 RES,100K
R216 0611077A76 RES,1.2K
R217 0611077A52 RES,120
Ref. Des. Part Number Description
R218 0611077B23 RES,100K
R219 0611077A98 RES,10K
R220 0611077A98 RES,10K
R221 0611077A74 RES,1K
R222 0611077A74 RES,1K
R223 0611077A76 RES,1.2K
R224 0611077A52 RES,120
R225 0611077B23 RES,100K
R226 0611077A98 RES,10K
R227 0611077A98 RES,10K
R228 0611077A76 RES,1.2K
R229 0611077A52 RES,120
R230 0611077A74 RES,1K
R231 0611077B23 RES,100K
R232 0611077A90 RES,4.7K
R233 0611077A98 RES,10K
R236 0611077A98 RES,10K
R237 0611077A80 RES,1.8K
R238 0611077A01 RES,0
R239 0611077A94 RES,6.8K
R240 0680194M18 RES,51
R241 0611077A98 RES,10K
S101 4083706T01 SWITCH
T100 2584422T01 XFMR
U100 5105109Z13 LT1129CQ
U101 5113819A04 MC3303
U102 5113819A04 MC3303
U103 5113805A01 MC74HC00A
U104 5113816A07 MC78M05
U105 5113819A05 MC33074A
U106 5113806A20 MC14053B
U107 5113819A04 MC3303
Ref. Des. Part Number Description
VR100 4813830A28 MMBZ5245B
VR101 4813830A18 MMBZ5235B
VR102 4813830A18 MMBZ5235B
VR103 4813830A18 MMBZ5235B
VR104 4813830A23 MMBZ5240B
VR105 4813830A15 MMBZ5232B
VR107 4813830A15 MMBZ5232B
VR108 4813830A18 MMBZ5235B
VR109 4813830A18 MMBZ5235B
VR110 4813830A18 MMBZ5235B
VR112 4813830A28 MMBZ5245B
VR113 4813832C28 MMBZ15
VR114 4813832C28 MMBZ15
VR115 4813832C28 MMBZ15
VR116 4813832C28 MMBZ15
Ref. Des. Part Number Description

Motorola ASTRO SPECTRA Specifications

General

Frequency Range	136-174 MHz, 403-470 MHz
Number of Channels	Up to 255
Channel Spacing	12.5 kHz, 20 kHz, 25 kHz
Modulation	FM
Operating Temperature	-22°F to +140°F (-30°C to +60°C)
