Schematics, Overlays, and Parts Lists: List of Schematics, Component Location Diagrams, and Parts Lists 8-47
6881096C77-O September 26, 2003
HLN6459D W3 Low-Power Interconnect Parts List
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C732 2113740B65 CAP CHIP REEL CL1 +/-30 470
C750 2113740B65 CAP CHIP REEL CL1 +/-30 470
C751 2113740B65 CAP CHIP REEL CL1 +/-30 470
C752 2113740B65 CAP CHIP REEL CL1 +/-30 470
C753 2113740B65 CAP CHIP REEL CL1 +/-30 470
C754 2113740B65 CAP CHIP REEL CL1 +/-30 470
C755 2113740B65 CAP CHIP REEL CL1 +/-30 470
C756 2113740B65 CAP CHIP REEL CL1 +/-30 470
C757 2113740B65 CAP CHIP REEL CL1 +/-30 470
C758 2113740B65 CAP CHIP REEL CL1 +/-30 470
C759 2113740B65 CAP CHIP REEL CL1 +/-30 470
C760 2113740B65 CAP CHIP REEL CL1 +/-30 470
C761 2113740B65 CAP CHIP REEL CL1 +/-30 470
C762 2113740B65 CAP CHIP REEL CL1 +/-30 470
C763 2113740B65 CAP CHIP REEL CL1 +/-30 470
C764 2113740B65 CAP CHIP REEL CL1 +/-30 470
C765 2113740B65 CAP CHIP REEL CL1 +/-30 470
C766 2113740B65 CAP CHIP REEL CL1 +/-30 470
C767 2113740B65 CAP CHIP REEL CL1 +/-30 470
C768 2113740B65 CAP CHIP REEL CL1 +/-30 470
C769 2113740B65 CAP CHIP REEL CL1 +/-30 470
C770 2113740B65 CAP CHIP REEL CL1 +/-30 470
C771 2113740B65 CAP CHIP REEL CL1 +/-30 470
C772 2113740B65 CAP CHIP REEL CL1 +/-30 470
C773 2113740B65 CAP CHIP REEL CL1 +/-30 470
C774 2113740B65 CAP CHIP REEL CL1 +/-30 470
C776 NOTPLACED 64AM DUMMY PART NUMBER
C777 NOTPLACED 64AM DUMMY PART NUMBER
C778 NOTPLACED 64AM DUMMY PART NUMBER
C779 2113740B65 CAP CHIP REEL CL1 +/-30 470
C780 2113740B65 CAP CHIP REEL CL1 +/-30 470
C781 2113740B65 CAP CHIP REEL CL1 +/-30 470
C783 2113740B65 CAP CHIP REEL CL1 +/-30 470
C784 2113740B65 CAP CHIP REEL CL1 +/-30 470
C785 2113741N69 CAP CHIP CL2 X7R 10%
100000
C786 2113741N69 CAP CHIP CL2 X7R 10%
100000
C787 2113741N45 CAP CHIP CL2 X7R 10% 10000
C788 2113741N45 CAP CHIP CL2 X7R 10% 10000
C789 2311049J26 CAP TANT CHIP 10 20 16
C790 2113740B65 CAP CHIP REEL CL1 +/-30 470
C791 2311049J26 CAP TANT CHIP 10 20 16
C792 2311049A37 CAP TANT CHIP 1 20 20
CR600 4813833C10 DIODE GEN PUR 70V
MMBD6050
CR601 4813833C10 DIODE GEN PUR 70V
MMBD6050
CR602 4813833C10 DIODE GEN PUR 70V
MMBD6050
CR603 4813833C10 DIODE GEN PUR 70V
MMBD6050
CR604 4813833C10 DIODE GEN PUR 70V
MMBD6050
CR605 4813833C10 DIODE GEN PUR 70V
MMBD6050
F600 NOTPLACED 64AM DUMMY PART NUMBER
HD001 0300139581 SCR MCH 4-40X5/16 PHLPAN
STL
HD002 0300139581 SCR MCH 4-40X5/16 PHLPAN
STL
HD003 0300139581 SCR MCH 4-40X5/16 PHLPAN
STL
HD004 0300139581 SCR MCH 4-40X5/16 PHLPAN
STL
J5 0980159P02 CONNECTOR 25-PIN
J6 0980159P02 CONNECTOR 25-PIN
JU10 NOTPLACED 64AM DUMMY PART NUMBER
JU11 NOTPLACED 64AM DUMMY PART NUMBER
JU12 NOTPLACED 64AM DUMMY PART NUMBER
JU512 NOTPLACED 64AM DUMMY PART NUMBER
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
JU513 NOTPLACED 64AM DUMMY PART NUMBER
JU600 0611077A01 RES CHIP JUMPER
JU601 NOTPLACED 64AM DUMMY PART NUMBER
JU602 0611077A01 RES CHIP JUMPER
JU603 NOTPLACED 64AM DUMMY PART NUMBER
JU604 0611077A01 RES CHIP JUMPER
JU605 NOTPLACED 64AM DUMMY PART NUMBER
JU606 0611077A01 RES CHIP JUMPER
JU607 0611077A01 RES CHIP JUMPER
JU608 0611077A01 RES CHIP JUMPER
JU609 0611077A01 RES CHIP JUMPER
JU610 NOTPLACED 64AM DUMMY PART NUMBER
JU611 NOTPLACED 64AM DUMMY PART NUMBER
JU612 0611077A01 RES CHIP JUMPER
JU613 NOTPLACED 64AM DUMMY PART NUMBER
JU614 0611077A01 RES CHIP JUMPER
JU615 0611077A01 RES CHIP JUMPER
JU616 0611077A01 RES CHIP JUMPER
JU617 NOTPLACED 64AM DUMMY PART NUMBER
JU618 0611077A01 RES CHIP JUMPER
JU619 0611077A01 RES CHIP JUMPER
JU620 0611077A01 RES CHIP JUMPER
JU621 0611077A01 RES CHIP JUMPER
JU622 0611077A01 RES CHIP JUMPER
JU623 0611077A01 RES CHIP JUMPER
JU624 NOTPLACED 64AM DUMMY PART NUMBER
JU625 NOTPLACED 64AM DUMMY PART NUMBER
JU626 0611077A01 RES CHIP JUMPER
JU627 0611077A01 RES CHIP JUMPER
JU628 NOTPLACED 64AM DUMMY PART NUMBER
JU629 NOTPLACED 64AM DUMMY PART NUMBER
JU630 NOTPLACED 64AM DUMMY PART NUMBER
JU631 NOTPLACED 64AM DUMMY PART NUMBER
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
JU632 0611077A01 RES CHIP JUMPER
JU633 NOTPLACED 64AM DUMMY PART NUMBER
JU634 NOTPLACED 64AM DUMMY PART NUMBER
JU635 NOTPLACED 64AM DUMMY PART NUMBER
JU636 NOTPLACED 64AM DUMMY PART NUMBER
JU637 0611077A01 RES CHIP JUMPER
JU638 0611077A01 RES CHIP JUMPER
JU640 0611077A01 RES CHIP JUMPER
JU641 0611077A01 RES CHIP JUMPER
JU642 0611077A01 RES CHIP JUMPER
JU643 NOTPLACED 64AM DUMMY PART NUMBER
JU644 NOTPLACED 64AM DUMMY PART NUMBER
JU645 NOTPLACED 64AM DUMMY PART NUMBER
JU650 0611077A01 RES CHIP JUMPER
JU651 NOTPLACED 64AM DUMMY PART NUMBER
JU652 0611077A01 RES CHIP JUMPER
JU653 NOTPLACED 64AM DUMMY PART NUMBER
JU654 0611077A01 RES CHIP JUMPER
JU655 2113741N69 CAP CHIP CL2 X7R 10%
100000
JU656 0611077A01 RES CHIP JUMPER
JU657 NOTPLACED 64AM DUMMY PART NUMBER
JU658 NOTPLACED 64AM DUMMY PART NUMBER
JU659 0611077A01 RES CHIP JUMPER
P502 2880102M09 PLUG VERTICAL 38 POSITION
P506 2880068M01 HEADER MIC
Q601 4880048M01 TSTR NPN DIG 47K/47K
Q602 4813821A32 TSTR P-CH PWR FET 60V 5A
Q603 4880052M01 TSTR NPN DRLNGTN MXTA27
Q604 4880052M01 TSTR NPN DRLNGTN MXTA27
R600 NOTPLACED 64AM DUMMY PART NUMBER
R601 NOTPLACED 64AM DUMMY PART NUMBER
R602 NOTPLACED 64AM DUMMY PART NUMBER
R603 NOTPLACED 64AM DUMMY PART NUMBER
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
