Motorola ASTRO W3 - Page 116

8-48 Schematics, Overlays, and Parts Lists: List of Schematics, Component Location Diagrams, and Parts Lists September 26, 2003 6881096C77-O
R604 NOTPLACED 64AM DUMMY PART NUMBER R605 NOTPLACED 64AM DUMMY PART NUMBER R606 NOTPLACED 64AM DUMMY PART NUMBER R607 NOTPLACED 64AM DUMMY PART NUMBER R608 0611077A01 RES CHIP JUMPER R609 0611077B15 RES CHIP 47K 5 1/8W R610 0611077B15 RES CHIP 47K 5 1/8W R612 0611077B23 RES CHIP 100K 5 1/8W R613 0611077B15 RES CHIP 47K 5 1/8W R614 0611077A98 RES CHIP 10K 5 1/8W R615 0611077A98 RES CHIP 10K 5 1/8W R616 0611077A98 RES CHIP 10K 5 1/8W R617 0611077A98 RES CHIP 10K 5 1/8W R618 0611077A96 RES CHIP 8200 5 1/8 R619 0611077B15 RES CHIP 47K 5 1/8W R620 0611077A54 RES CHIP 150 5 1/8W R621 0611077A74 RES CHIP 1000 5 1/8 R622 0611077A74 RES CHIP 1000 5 1/8 R623 0611077A74 RES CHIP 1000 5 1/8 U600 NOTPLACED 64AM DUMMY PART NUMBER U601 5113806A05 IC FLIP-FLOP,DUAL D U602 5113806A37 IC SCHMITT TRIGGER,HEX U603 5113816A19 IC ADJ LO DROPOUT POS
REG .8A
VR600 4813830A28 DIODE 15V 5% 225MW
MMBZ5245B_
VR601 4813830A28 DIODE 15V 5% 225MW
MMBZ5245B_
VR602 4813830A28 DIODE 15V 5% 225MW
MMBZ5245B_
VR603 4813830A28 DIODE 15V 5% 225MW
MMBZ5245B_
VR604 4813830A28 DIODE 15V 5% 225MW
MMBZ5245B_
VR605 4813830A28 DIODE 15V 5% 225MW
MMBZ5245B_
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
VR606 4813830A28 DIODE 15V 5% 225MW
MMBZ5245B_
VR607 4813830A28 DIODE 15V 5% 225MW
MMBZ5245B_
VR608 4813830A28 DIODE 15V 5% 225MW
MMBZ5245B_
VR609 4813830A28 DIODE 15V 5% 225MW
MMBZ5245B_
VR610 4813830A28 DIODE 15V 5% 225MW
MMBZ5245B_
VR611 4813830A28 DIODE 15V 5% 225MW
MMBZ5245B_
VR612 4813830A28 DIODE 15V 5% 225MW
MMBZ5245B_
VR613 4813830A28 DIODE 15V 5% 225MW
MMBZ5245B_
VR614 4813832C28 ZENER BPLR 15V FOR ESD
SOT23
VR615 4813832C28 ZENER BPLR 15V FOR ESD
SOT23
VR616 4813832C28 ZENER BPLR 15V FOR ESD
SOT23
VR617 4813832C28 ZENER BPLR 15V FOR ESD
SOT23
VR618 4813830A28 DIODE 15V 5% 225MW
MMBZ5245B_
VR619 4813830A28 DIODE 15V 5% 225MW
MMBZ5245B_
VR620 4813830A28 DIODE 15V 5% 225MW
MMBZ5245B_
VR621 4813830A28 DIODE 15V 5% 225MW
MMBZ5245B_
VR622 4813830A28 DIODE 15V 5% 225MW
MMBZ5245B_
VR623 4813830A28 DIODE 15V 5% 225MW
MMBZ5245B_
VR624 4813830A28 DIODE 15V 5% 225MW
MMBZ5245B_
VR625 4880140L23 DIODE SOT ZENER 18V
TAPE&REEL
VR626 4813830A28 DIODE 15V 5% 225MW
MMBZ5245B_
VR627 NOTPLACED 64AM DUMMY PART NUMBER
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
