Schematics, Overlays, and Parts Lists: List of Schematics, Component Location Diagrams, and Parts Lists 8-49 6881096C77-O September 26, 2003 HLN6365E Motorcycle Interconnect Parts List
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C754 2113740B65 CAP CHIP REEL CL1 +/-30 470 C755 2113740B65 CAP CHIP REEL CL1 +/-30 470 C772 2113741N45 CAP CHIP CL2 X7R 10% 10000 C773 2113741N45 CAP CHIP CL2 X7R 10% 10000 GS1 4205747Z01 CLIP GRND GS2 4205747Z01 CLIP GRND J5 0980159P02 CONNECTOR 25-PIN JU12 0611077A01 RES CHIP JUMPER JU512 0611077A01 RES CHIP JUMPER JU513 0611077A01 RES CHIP JUMPER JU600 0611077A01 RES CHIP JUMPER JU601 0611077A01 RES CHIP JUMPER JU603 0611077A01 RES CHIP JUMPER JU604 0611077A01 RES CHIP JUMPER JU606 0611077A01 RES CHIP JUMPER JU607 0611077A01 RES CHIP JUMPER JU608 0611077A01 RES CHIP JUMPER JU609 0611077A01 RES CHIP JUMPER JU612 0611077A01 RES CHIP JUMPER JU613 0611077A01 RES CHIP JUMPER JU619 0611077A01 RES CHIP JUMPER JU620 0611077A01 RES CHIP JUMPER JU621 0611077A01 RES CHIP JUMPER JU622 0611077A01 RES CHIP JUMPER JU623 0611077A01 RES CHIP JUMPER JU631 0611077A01 RES CHIP JUMPER JU632 0611077A01 RES CHIP JUMPER JU637 0611077A01 RES CHIP JUMPER JU638 0611077A01 RES CHIP JUMPER JU640 0611077A01 RES CHIP JUMPER JU641 0611077A01 RES CHIP JUMPER JU642 0611077A01 RES CHIP JUMPER
JU651 0611077A01 RES CHIP JUMPER JU654 0611077A01 RES CHIP JUMPER JU656 0611077A01 RES CHIP JUMPER JU657 0611077A01 RES CHIP JUMPER JU659 0611077A01 RES CHIP JUMPER P502 2880102M09 PLUG VERTICAL 38 POSITION P506 2880068M01 HEADER MIC R608 0611077A74 RES CHIP 1000 5 1/8 R618 0611077A96 RES CHIP 8200 5 1/8 VR600 4813830A28 DIODE 15V 5% 225MW
MMBZ5245B_
VR601 4813830A28 DIODE 15V 5% 225MW
MMBZ5245B_
VR602 4813830A28 DIODE 15V 5% 225MW
MMBZ5245B_
VR603 4813830A28 DIODE 15V 5% 225MW
MMBZ5245B_
VR604 4813830A28 DIODE 15V 5% 225MW
MMBZ5245B_
VR605 4813830A28 DIODE 15V 5% 225MW
MMBZ5245B_
VR606 4813830A28 DIODE 15V 5% 225MW
MMBZ5245B_
VR607 4813830A28 DIODE 15V 5% 225MW
MMBZ5245B_
VR608 4813830A28 DIODE 15V 5% 225MW
MMBZ5245B_
VR609 4813830A28 DIODE 15V 5% 225MW
MMBZ5245B_
VR610 4813830A28 DIODE 15V 5% 225MW
MMBZ5245B_
VR611 4813830A28 DIODE 15V 5% 225MW
MMBZ5245B_
VR612 4813830A28 DIODE 15V 5% 225MW
MMBZ5245B_
VR613 4813830A28 DIODE 15V 5% 225MW
MMBZ5245B_
VR618 4813830A28 DIODE 15V 5% 225MW
MMBZ5245B_
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
VR619 4813830A28 DIODE 15V 5% 225MW
MMBZ5245B_
VR620 4813830A28 DIODE 15V 5% 225MW
MMBZ5245B_
VR621 4813830A28 DIODE 15V 5% 225MW
MMBZ5245B_
VR622 4813830A28 DIODE 15V 5% 225MW
MMBZ5245B_
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
