Chapter 7 Exploded Views and Parts Lists
This chapter contains the exploded views and associated parts lists for each of the ASTRO Digital Spectra and Digital Spectra Plus control heads. Tables containing pushbutton parts lists are also included.
Table 7-1. Exploded Views
Fig # Description Page #
Figure 7-1 W3 Hand-Held Control Head Exploded View 7-2
Figure 7-2 W4 Rotary Control Head Exploded View 7-3
Figure 7-3 W5 and W7 Pushbutton Control Head Exploded View 7-4
Figure 7-4 W9 Pushbutton Control Head Exploded View 7-5
Figure 7-5 HMN1080A, HMN1061A, HMN1079A Microphone Exploded View 7-6
