Motorola ASTRO XTS 2500 III User Manual

ASTRO Digital XTS 2500 Model III 27
General Radio Operation
Antenna
Your radio’s operating frequency is 764 to 870 MHz. For information
regarding other available antennas, see page 91.
Attach the Antenna
Remove the Antenna
With the radio off, turn the
antenna clockwise to attach it.
With the radio off, turn the
antenna counter-clockwise to
remove it.

Motorola ASTRO XTS 2500 III Specifications

General

GPS	Optional
Bluetooth	No
Weight	14.5 oz (with standard battery)
Audio Output	1W (internal speaker)
Encryption	DES, AES
Signaling	MDC1200, DTMF, Quick Call II
Operating Temperature	-30°C to +60°C (-22°F to +140°F)
Display	Alphanumeric LCD
