6809456A82 January 23, 2003 11
Level 1 and 2 Service Manual General Operation
Display animation makes the phone’s icon menu move smoothly as the user scrolls
up and down.
Figure 2 shows some common icons displayed on the LCD.
1. Signal Strength shows the strength of the phone’s connection with the
network. Calls cannot be sent or received when the “no signal” indicator is
displayed.
2. In Use Indicator icon indicates a call in progress.
3. Roam Indicator icon appears when the phone uses another network system
outside the user’s home network. When leaving the home network area, the
phone roams, or seeks, another network.
4. Message Waiting Indicator
4
appears when the phone receives a text mes-
sage.
5. Voice Message Waiting Indicator
4
icon indicates when the phone receives
a voicemail message.
6. Battery Level Indicator shows the amount of charge left in the battery.
7. Real Time Clock shows the current time.
8. Menu Indicator provides access to the phone’s main menu.
9. GPRS Indicator
4
indicates when the phone is currently functioning in GPRS
mode.
10. Alert Setting Indicator indicates the phones current ringer alert setting.
➧
Whether a phone displays all indicators depends on the programming and services
to which the user subscribes.
020158o
Figure 2. C350 Display Icon Indicators
4. Network, subscription and SIM card or service provider dependent feature. Not available in all areas.
Signal
Strength
Indicator
Batter
