6809456A82 January 23, 2003 21
Level 1 and 2 Service Manual Disassembly
3. To replace, align the rear housing cover to the front housing
4. Gently press the rear housing cover into position onto the front housing until
the rear housing cover snaps into place.
021023o
Figure 4. Removing the Rear housing Cover
LATCH
REAR HOUSING COVER
REAR HOUSING COVER
FRONT HOUSING
021023
