Figure 11: Programming the Radio through a Multi-Unit Charger
2 Set the cable switch to analog.
3 After the radio is connected, open the CPS and select Read on the toolbar to get the radio
profile.
You can change the general, audio, menu, channels, scan list, customized PL/DPL settings and
select frequencies and PL/DPL codes on each channel.
4 To save the settings, select Write to radio on the toolbar.
NOTICE: For more information on the CPS, see Help menu in the CPS.
Factory Default Settings
Your radio is programmed at the factory to the following settings.
Table 8: CLP446e Defaults
Channel Number Frequency Settings
(MHz)
Code Value (Hz) Bandwidth (kHz)
1 446.00625 67.0 12.5
2 446.01875
3 446.03125
4 445.04375
5 446.05625
6 446.06875
MN006181A01-AA
Radio Programming through CPS
30
