• Two SUC kits with a cloning cable (HKKN4028_).
• Both radios are turned off.
•
A source radio that consists of the radio profile to be cloned to the target radio.
• A target radio that consists of the radio to which the profile will be updated with the source radio
profile.
Figure 8: Radio to Radio Cloning
Procedure:
1 Unplug any cables such as power supply or micro USB cables from the SUC.
2 Plug one side of the cloning cable micro USB to one SUC and plug the other end to the second
SUC.
NOTICE: HKKN4028_ cable switch can be in "Legacy" or "Cloning" position.
During the cloning process, no power is applied to the SUC. The batteries cannot be charged. A
data communication is established between the two radios.
3 Turn on the target radio and place it into one of the SUC.
4 To power the source radio, press and hold the PTT button and the - button simultaneously while
turning on the radio until you hear the cloning tone.
5 To start the cloning process, press and release the Menu button.
NOTICE: If successful, you can observe the following:
• the source radio sounds a good key chirp tone.
•
both radios flash green before the source radio returns to cloning mode.
• the target radio restarts.
NOTICE: If unsuccessful, you can observe the following sequence on the source radio:
• flashes red.
•
sounds a double "bonk" tone.
6 Turn the source radio off and on to exit the cloning mode and return to user mode after the
cloning process is completed.
NOTICE: When the radio is in clone mode, the Auto Power Off feature is not applicable.
MN007428A01-AB
Chapter 5: Radio Cloning
32
