Mechanical Views and Parts Lists 3-15
Item
Motorola
Part
Number
Description
1 See Chapter 6 Antenna
2 3680529Z01 Knob, Volume
3 3680530Z02 Knob, Frequency
4 1380525Z01 Escutcheon, Top
5 3385681Z01 Escutcheon, Label
6 3280533Z03 Seal, Control Top
7 6180527Z01 Lightpipe, Tx
8 1364279B10
1364279B12
Nameplate label GP240
Nameplate label GP540
9 1586059A01 Dust Cover, Universal
Connector
10 1386058A01 Escutcheon, Universal Flex
11 1580666Z03 Front Cover, Basic
12 Not Field
Replaceable
Escutcheon, FM
13 7580532Z01 Keypad, Side Control
14 1386324Z01 Bezel, Side Control
15 7585265Z03 Keypad, Blank
16 0104007J99 Keypad Board Assembly
17 4286266Z01 Retainer, Keypad PCB
18 3586057A01 Felt Speaker
19 1480577C01 Boot, Microphone
20 5085738Z03 Speaker
21 5013920A04 Microphone
22 8480549Z06 Flex, UC
23 2113740A41 Capacitor, 33pF
24 4280504Z01 Retainer, Speaker
25 0304726J04 Screw
26 See Chapter 6 Back Cover Kit incl. chassis
main board
27 8480475Z03 Flex, Keypad/Controller
28 1485673Z01 Insulator, Antenna
29 7580556Z01 Pad, Thermal
30 3280534Z01 Seal, Contact
31 3280536Z01 Gasket, O-Ring
32 3980698Z01 Contact, Ground, Compliant,
VHF
33 2780518Z01 Chassis
34 See Chapter 6 Battery
35 HLN9714A Belt Clip
Item
Motorola
Part
Number
Description
