6-6 MODEL CHART AND TEST SPECIFICATION
4.3 Receiver
*Availability subject to the laws and regulations of individual countries.
Receiver UHF/800 VHF
*Frequencies - Full Bandsplit
UHF: 403-470 MHz
800MHz: 851-870 MHz
136-174 MHz
Channel Spacing UHF: 12.5/20/25 kHz
800MHz: 20/25kHz
12.5/20/25 kHz
Sensitivity (12 dB SINAD) EIA 0.35 µV
Intermodulation EIA
- 65dB
Adjacent Channel Selectivity -70dB
Frequency Stability
(-30°C to +60°C, +25° Ref.)
±1.5 ppm ±2.5 ppm
Spurious Rejection - 70 dB
Image Rejection -70 dB
Audio Output @ <5% Distortion 0.5W
Audio Distortion @ Rated Audio <3% typical
