3-18 MAINTENANCE
9.0 Service Aids
Table 3-1 lists service aids recommended for working on the GP200/500 Series Radios.
While all of these items are available from Motorola, most are standard shop equipment items, and
any equivalent item capable of the same performance may be substituted for the item listed.
Table 3-1 Service Aids
Motorola Part
Number
Description Application
RLN4460_ Portable & Mobile Test Set Enables connection to the audio/
accessory jack.
Allows switching for radio testing.
RKN4074_ RIB/Radio/Test Set Interconnect Cable Connects radio to Computer.
RKN4075_ Programming Cable with internal RIB Connects radio to Computer.
RLN4008_ Radio Interface Box (RIB) Enables communications between the
radio and the computer’s serial
communications adapter.
5885705M01 BNC Adaptor Adapts radio’s antenna port to BNC
cabling of test equipment.
5880384G68 SMA to BNC Adaptor Adapts radio’s antenna port to BNC
cabling of test equipment, 800MHz only.
HLN9742_ Flash Upgrade Adapter Provides connections to the computer or
RIB programming /test cable.
RLN4510_ Battery Elliminator 7.5 VDC Includes protection circuit
0180305G54 Battery Adapter with cable to RLN4510 Connects radio to Battery Elliminator
8180384F68 Bench Test Housing Eliminator. Provides for troubleshooting of the radio
when the housing is removed.
EPN4040_ Wall-Mounted Power Supply (UK) for RLN4008
EPN4041_ Wall-Mounted Power Supply(220VAC) for RLN4008
3080369B71 Computer Interface Cable 25 to 9 pin (RLN4008_ to IBM PC).
3080369B72 Computer Interface Cable 9 to 9 pin (RLN4008_ to IBM PC).
