Test Equipment 3-19
10.0 Test Equipment
Table 3-2 lists test equipment required to service the GP200/500 Series and other two-way radios.
Table 3-2 Recommended Test Equipment
Motorola Part
Number
Description Characteristics
Application
R2670_
RLN4498_
1580357B77
Comms System Analyzer
with FDMA
Analog Trunking
Smartnet/Zone
Canvas Case
This monitor will
substitute for items
with an asterisk*.
Protects Units
Frequency/deviation meter and
signal generator for widerange
troubleshooting and alignment
Option for R2670_.
when used in the Field.
* WADN4133_ Oscilloscope Analog 2 Channel
40MHz bandwidth,
5mV/cm - 20 V/cm.
Waveform measurements.
* R1072_ Digital Multimeter AC/DC voltage and current
measurements.
* R1377_ AC Voltmeter 100µV to 300V, 5Hz -
1MHz, 10Mohm input
impedance.
Audio voltage measurements.
* R1440_
* 0180305F29
* 0180305F38
* 0180305F46
* RLN5417_
* T1013_
Wattmeter,
Plug-in Element
Plug-in Element
Plug-in Element
Carry case for Wattmeter
RF Dummy Load
Thruline 50-Ohm,
±5% accuracy.
5W, 100-250MHz
5W, 200-500MHz
5W, 400-1000MHz
plus elements
Transmitter power output
measurements.
WADN4243_ Power Supply (220V) Bench top Programmable
S1339_/220 RF Millivolt Meter 100mV to 3 V RF.
10kHz to 1.2GHz
RF level measurements.
0100855414 RF Cable 2 male BNC Conn.
1.5m (3 pcs needed)
