3-20 MAINTENANCE
Table 3-3 lists the recommended tools used for maintaining this family of radios.
These tools are also available from Motorola
Table 3-3 Recommended Test Tools
Motorola Part
Number
Description Application
6680702Z01 Chassis opener and knob removal
tool.
Disassembly tool.
RSX4043_ Torx Driver Tighten and remove chassis screws.
6680387A70 T-6 Torx Bit Removable Torx driver bit (2 pcs).
WADN4055_
6604008K01
6604008K02
Portable soldering station
0.4mm replacement tip
0.8mm replacement tip
Digitally controlled soldering Iron
For WADN4055_ soldering Iron
For WADN4055_ soldering Iron
1010041A86 Solder (RMA type),
63/37, 0.5mm diameter
1 lb. spool.
0180386A78 Illuminated magnifying glass with
lens attachment.
0180386A82 Anti-static grounding kit. Used during all radio assembly and
disassembly procedures.
0180303E45 SMD tool kit
incl. probers and brush.
R1321_ Shields and surface-mounted
component and IC removal/rework
station (order all heat-focus heads
separately).
Removal and assembly of
surface-mounted integrated circuits and
shields.
6680332E82
6680332E84
6680333E55
6680332E90
Nozzle 20.3 x 20.3 mm
Nozzle 12.7 x 12.7 mm
Nozzle 16.5 x 25.4 mm
Nozzle 24.1 x 24.1 mm
Heat-focus heads for
R1321 work station.
