Mechanical Views and Parts Lists 3-17
NOTE: When intending to replace a front housing, keypad
or keypad front cover, check your radio to determine if the
Motorola logo is printed on the housing, or printed on a
label/escutcheon above the speaker grille. If the logo is
printed on the housing, replace ALL the following parts:
front housing (11), keypad (15) and keypad retainer (20).
If the logo is printed on a label/escutcheon, replace the
individual parts independently.
When replacing the front housing it is recommended that
the three adhesive pieces be replaced.
Item
Motorola
Part
Number
Description
1 See Chapter 6 Antenna
2 3680529Z01 Knob, Volume
3 3680530Z02 Knob, Frequency
4 1380525Z03 Escutcheon, Top
5 3385681Z01 Escutcheon, Label
6 3280533Z03 Seal, Control Top
7 6180527Z01 Lite Pipe, Tx
8 1364279B13
1364279B11
Nameplate, GP580
Nameplate, GP280
9 1586059A01 Dust Cover, Universal
Connector
10 1386058A01 Escutcheon, Universal Flex
11 1586335Z02 Front Cover, Display with
Full Keypad (DTMF)
12 Not Field
Replaceable
Escutcheon, FM
13 7580532Z01 Keypad, Side Control
14 1386324Z01 Bezel, Side Control
15 7586265Z03 Keypad
16 0104007J99 Keypad Board Assembly
17 7580540Z01 Pad, Display
18 5104949J07 LCD Module
19 7580637Z01 Pad, LCD Back
20 4286266Z01 Retainer, Keypad PCB
21 3586057A01 Felt Speaker
22 1480577C01 Boot, Microphone
23 5085962A02 Speaker
24 5013920A04 Microphone
25 8480549Z01 Flex, UC
26 2113740A41 Capacitor, 33pF
27 4280504Z01 Retainer, Speaker
28 1480503Z01 Boot, Backup Battery
29 6062884G01 Backup Battery
30 0304726J04 Screw
31 3980667Z01 Contact, Finger
32 See Chapter 6 Back Cover Kit incl. chassis
main board
33 8480475Z03 Flex, Keypad/Controller
34 1480652Z01 Insulator, Antenna
35 7580556Z01 Pad, Thermal
36 3280534Z01 Seal, Contact
37 3280536Z01 Gasket, O-Ring
38 3980698Z01 Contact, Ground, Compliant
39 2780518Z01 Chassis
40 See Chapter 6 Battery
41 HLN9714A Belt Clip
Item
Motorola
Part
Number
Description
