Test Mode 4-3
3.1.3 Keypad
Test the keypad as follows:
1. Press 0, view “48/1”; release, view “48/0”.
2. Press 1, view “49/1”; release, view “49/0”.
3. Press 2, view “50/1”; release, view “50/0”.
4. Press 3, view “51/1”; release, view “51/0”.
5. Press 4, view “52/1”; release, view “52/0”.
6. Press 5, view “53/1”; release, view “53/0”.
7. Press 6, view “54/1”; release, view “54/0”.
8. Press 7, view “55/1”; release, view “55/0”.
9. Press 8, view “56/1”; release, view “56/0”.
10. Press 9, view “57/1”; release, view “57/0”.
11. Press *, view “58/1”; release, view “58/0”.
12. Press #, view “59/1”; release, view “59/0”.
13. Press <, view “128/1”; release, view “128/0”.
14. Press HOME, view “129/1”; release, view “129/0”.
15. Press >, view “130/1”; release, view “130/0”.
16. Press Option Select1, view “135/1”; release, view “135/0”.
17. Press Option Select2, view “136/1”; release, view “136/0”.
18. Press Option Select3, view “137/1”; release, view “137/0”.
19. Pressing SB2 for 3 seconds in the Control Head Test mode will cause the radio to return to
the RF Test mode.
Table 4-2 Test Environments
Item
No.
No. of
Beeps
Description Function
1 1
BKC
Carrier Squelch RX: unsquelch if carrier detected
TX: mic audio
21
BKC
Tone
Private-Line
RX: unsquelch if carrier and tone (192.8Hz) detected
TX: mic audio + tone (192.8Hz)
3 2
BKC
Digital
Private-Line
RX: unsquelch if carrier and digital code (131) detected
TX: mic audio + digital code (131)
43
BKC
Dual-Tone multi-
ple frequency
RX: unsquelch if carrier detected
TX: selected DTMF tone pair
5 5
BKC
Open squelch
OSQ
RX: constant unsquelch
TX: mic audio
68
BKC
Trunking Low
Speed TLS
RX: unsquelch if carrier detected
TX: mic audio + connect tone (105-8 MHz)
7 9
BKC
Trunking High
Speed THS
RX: unsquelch if valid outbound signalling word (OSW) detected
TX: 1500Hz tone
811
BKC
CMP RX: unsquelch if carrier detected
TX: mic audio
9 12
BKC
LLE RX: unsquelch if carrier detected
TX: mic audio
