Motorola GP88s

9B -32 Circuit Board/Schematic Diagrams and Parts List
VHF Radio Parts List
Circuit
Ref
Motorola
Part No.
Description
B501 0986237A02 Battery Contact
C3200 2113743N31 16pF
C3201 Not Placed
C3202 Not Placed
C3203 2113743N50 100pF
C3204 2113743L41 10000pF, 10%
C3205 2113928N01 0.1uF
C3206 2113743L41 10000pF, 10%
C3207 2113743N10 2.2pF
C3208 Not Placed
C3209 2311049A07 1uF
C3210 2113743L17 1000pF
C3211 2311049A56 4.7uF
C3212 2311049A07 1uF
C3213 2311049A56 4.7uF
C3214 2113928N01 0.1uF
C3215 2113743N26 10pF
C3218 2311049A56 4.7uF
C3219 2113928N01 0.1uF
C3220 2113743N26 10pF
C3221 2113743L41 10000pF, 10%
C3222 2113928N01 0.1uF
C3223 2113928N01 0.1uF
C3224 2113928N01 0.1uF
C3225 2113928N01 0.1uF
C3226 2113928N01 0.1uF
C3227 2113743L41 10000pF, 10%
C3228 2113743L41 10000pF, 10%
C3229 2113743N50 100pF
C3230 2113740F51 100pF
C3231 2180478Z20 1uF
C3232 2180478Z20 1uF
C3233 2180478Z20 1uF
C3234 2180478Z20 1uF
C3235 2113743A23 0.22uF
C3236 Not Placed
C3237 Not Placed
C3238 2113743A24 0.33uF
C3239 2113743E07 0.022uF
C3240 2113743A23 0.22uF
C3241 2113743L19 1200pF
C3242 2109720D14 0.1uF, 1206
C3243 2113743E07 0.022uF
C3244 2113743L41 10000pF, 10%
C3270 2113743E07 0.022uF
C3271 2113743L05 330pF
C3272 2113743N18 4.7pF
C3273 2113743N26 10pF
C3274 2113743N38 33pF
C3275 2113743N44 56pF
C3276 2113743N42 47pF
C3277 2113743N48 82pF
C3278 2113743E20 0.1uF
C3279 2311049A07 1uF
C3280 2113743L39 8200pF
C3301 2113743N29 13pF
C3302 2113743N54 150pF
C3303 2113743N33 20pF
C3304 2113743N54 150pF
C3305 Not Placed
C3306 2113928N01 0.1uF
C3307 2113743N50 100pF
C3308 2113743L05 330pF
C3309 2113928N01 0.1uF
C3310 Not Placed
C3311 2113743N54 150pF
C3312 2113743N31 16pF
C3313 2113743N54 150pF
C3314 Not Placed
C3315 2113743N26 10pF
C3316 2113743N33 20pF
C3317 2113743N40 39pF
C3318 2113743M08 22000pF, +80%/-20%
C3319 Not Placed
C3320 2113743N49 91pF
C3321 2113743L05 330pF
C3322 2113743N50 100pF
C3323 2113743N50 100pF
C3324 2113743N38 33pF
C3325 2113743L17 1000pF
C3326 Not Placed
C3327 2113743L05 330pF
C3329 2113743L05 330pF
C3330 2113743N50 100pF
C3331 2113743N50 100pF
C3332 2113743N40 39pF
C3334 2113743N33 20pF
C3335 2113743N34 22pF
C3336 2311049A18 10uF
C3337 2113743M08 22000pF, +80%/-20%
C3338 2113743L09 470pF
C3339 2113743N26 10pF
C3501 2113743L05 330pF
C3502 2113743N38 33pF
C3503 2113743N38 33pF
C3504 2113743M08 22000pF, +80%/-20%
C3505 2113743N38 33pF
C3506 Not Placed
C3507 Not Placed
C3508 2113743M08 22000pF, +80%/-20%
Circuit
Ref
Motorola
Part No.
Description
C3509 2113743L05 330pF
C3512 2113740F43 47pF
C3513 2113740F38 30pF
C3514 2113740F47 68pF
C3515 2113743L29 3300pF
C3516 2311049A08 1uF
C3518 Not Placed
C3519 Not Placed
C3521 2111078B51 220pF
C3523 2111078B45 130pF
C3524 2113740F34 20pF
C3525 2113740F35 22pF
C3526 2113743M08 22000pF, +80%/-20%
C3527 Not Placed GCAM Dummy Part Number
C3528 2113740F27 10pF
C3531 2113740F29 12pF
C3532 2113740F38 30pF
C3533 2113740F26 9.1pF
C3534 2113740F27 10pF
C3535 2113740F36 24pF
C3536 2113740F31 15pF
C3537 2113740F34 20pF
C3539 2113740F33 18pF
C3541 2113743M08 22000pF, +80%/-20%
C3542 2113743L05 330pF
C3543 2113743M08 22000pF, +80%/-20%
C3544 2113743L05 330pF
C3546 2113743L05 330pF
C3547 2113743M08 22000pF, +80%/-20%
C3550 2113743N33 20pF
C3551 2113743N49 91pF
C3552 2113743N44 56pF
C3560 2311049A07 1uF
C3561 2113743M08 22000pF, +80%/-20%
C3562 2113743L29 3300pF
C3563 2113743L29 3300pF
C3564 2113743L01 220pF
C3565 2113743E07 0.022uF
C3566 2113743N50 100pF
C3567 2113743L05 330pF
C3568 2113743L29 3300pF
C3569 2113743M08 22000pF, +80%/-20%
C3570 2113743L05 330pF
C3701 2113743L41 10000pF, 10%
C3702 2113743L41 10000pF, 10%
C3703 2113743L41 10000pF, 10%
C3704 2113743L41 10000pF, 10%
C3705 2113743E20 0.1uF
C3706 2311049J11 4.7uF
C3707 2113743N34 22pF
C3708 2113743M24 100000pF, +80%/-20%
Circuit
Ref
Motorola
Part No.
Description
C3709 2113743M24 100000pF, +80%/-20%
C3710 2104993J02 2.2uF
C3711 2311049A69 10uF, 20%
C3712 2113743M24 100000pF, +80%/-20%
C3713 2311049A09 2.2uF
C3714 2311049J11 4.7uF
C3715 2113743N50 100pF
C3716 2113743N50 100pF
C3721 2113743E20 0.1uF
C3722 2113743E20 0.1uF
C3724 2311049A08 1uF
C3725 Not Placed
C3726 2113743N24 8.2pF
C3727 2113743N50 100pF
C3731 2113743L41 10000pF, 10%
C3732 2113743L41 10000pF, 10%
C3733 2104993J02 2.2uF
C3734 2113743L41 10000pF, 10%
C3735 Not Placed
C3741 Not Placed
C3742 2113743L01 220pF
C3743 2113743L01 220pF
C3744 2113743L01 220pF
C3745 2113743L01 220pF
C3746 2113743L01 220pF
C3751 Not Placed
C3752 2113743L17 1000pF
C3753 2311049A56 4.7uF
C3754 2113743M24 100000pF, +80%/-20%
C3755 2104993J02 2.2uF
C3761 2113743N44 56pF
C3762 2113740F63 330pF
C3763 2113743N08 1.6pF
C3801 2113743N18 4.7pF
C3802 Not Placed
C3803 2113743L17 1000pF
C3804 2113743E20 0.1uF
C3805 2113743N18 4.7pF
C3806 2113743N50 100pF
C3808 2113743N30 15pF
C3809 2113743N36 27pF
C3810 Not Placed
C3811 2113743M24 100000pF, +80%/-20%
C3812 2113743M24 100000pF, +80%/-20%
C3813 2113743L41 10000pF, 10%
C3815 2113743L17 1000pF
C3816 2113743N22 6.8pF
C3818 2113743E07 0.022uF
C3821 2113743L41 10000pF, 10%
C3822 2113743L17 1000pF
C3823 2113743L41 10000pF, 10%
Circuit
Ref
Motorola
Part No.
Description
