Motorola GP88s

4-18 Mechanical View and Parts List
Item
Motorola
Part
Number
Description
1
See Section 2 Antenna
2 3680690Z01 Knob, Volume
3 3680147S07 Knob, Frequency
4 1380691Z01 Escutcheon, Top
5 3280722Z01 Seal, Control Shaft
6 6180968Y01 Lightpipe, Tx
7 3380725Z01 Label, Logo
8 3380726Z01 Label, Name
9 3880692Z01 Cap, Dust
10 1385605Z01 Bezel, Side Control
11 7580694Z01 Keypad, Side Control
12 1580695Z01
1580695Z02
Housing, Front (Plain)
Housing, Front (Keypad)
13 1380649Z03 Escutcheon, FM
14 7580720Z01
7580719Z01
Keypad, Dummy (Plain)
Keypad, Front (Display)
15 0104009J11 Keypad Board Assembly
16 4285609Z04 Retainer Plate
17 8480475Z03 Flex, Keypad/Controller
18 3585606Z01 Felt, Speaker
19 5085738Z04 Speaker
20 1480577C01 Boot, Microphone
21 5013920A04 Microphone
22 2113740A55 Cap, 100pF
23 0980727Z01 Connector, Wire
24 4285601Z01 Retainer, Speaker
25 1485798Z01 Insulator, Speaker
26 0304726J05 Screw
27 1586657Z01 Retainer, Jack
28 1585815Z01 Shroud, Jack
29 3980667Z01 Contact, Finger
30 7585734Z01 Pad, VCO Shield
31 3380564Z01 Label, Warning
32 See Section
9A & Section
9B
Back Cover Kit including
chassis main board
33 1585705Z01 Shroud, RF Jack
34 7580556Z01 Pad, Thermal
35 3280534Z02 Seal, Contact
36 3280536Z01 Gasket, O-ring
37 2780518Z03 Chassis
38 See Section 2 Battery
39 HLN9844A Beltclip
