General Display Information
The IMPRES
Adaptive Multi-Unit Charger with CDM provides the user
with valuable information while performing battery maintenance and
care. The information that the charger displays and the corresponding
LED indicators are detailed in the following tables.
Start Up
Non-IMPRES
Battery in the Pocket
IMPRES
Battery in the Pocket
Upon Charger Power-up
LED SINGLE FLASH GREEN
Line 1 IMPRES
Line 2
If There is No Battery in the Pocket
LED OFF
Line 1 NO BATTERY
Line 2
Reading Battery Data
LED Any Defined Indication
Line 1 READING
Line 2 BATTERY DATA
LED Defined by Charge State
Line 1 NON-IMPRES
Line 2 BATTERY
IMPRES and Software Versions are Displayed
LED Defined by Charge State
Line 1 IMPRES
Line 2 SW xx.yy; aa.bb
NOTE:
xx.yy denotes charger SW version, and aa.bb denotes CDM
SW version.
IMPRES
Battery Kit # and Chemistry are Displayed
LED Defined by Charge State
Line 1 KIT# --------
Line 2 -----CHEMISTRY
