BASIC LEVEL TEST MODES AND PROCEDURES: Test Mode Test Procedures
68P80400P73-A 6-7
e. Summary selection contains time and longitude/latitude expressed in degrees. Accuracy in
meters is also displayed.
f. GPS Version contains information about the custom Sirf software used in the unit.
13. Press Back to return to the Trace Mode display.
14. Scroll down to highlight IMEI/SIM ID, and then press OK to view the IMEI/SIM ID display.
The IMEI is the global name assigned to the mobile station at manufacturing time and should
correspond to the serial-number tag of the unit. The SIM ID is the SIM electronic serial number
and should correspond with the number stamped on the SIM card.
15. Press Back to return to the Trace Mode display.
16. Scroll down to highlight Registr Log, and then press OK to view the Registr Log display. This
screen displays the Dispatch Log, Interconnect Log, Packet Data Log, Mobile IP Log, and
Phone Rst Log. Registration Log information is updated when the user deselects and selects the
Registr Log choice.
17. Press Back to return to the Trace Mode display.
18. Scroll down to highlight Err/Chan Codes, and then press On to view the Err/Chan Codes
display. This screen displays the physical channel that the unit is connected to or the radio link
procedure that is currently active. Also, displays error codes of errors encountered during
normal operation if Err/Chan codes is On. (At power up, Err/Chan Codes is Off)
19. Press Back to return to the Trace Mode display.
20. Scroll down to highlight Current Freq, and then press OK to view the Current Freq display,
which shows the current frequency and band.
21. Press Back to return to the Trace Mode display.
22. Scroll down to highlight Dispatch IDs, and then press OK to view the Dispatch IDs display.
This screen displays the dispatch group id affiliated with the unit in the current dispatch-
location area. Also, displays the dispatch individual id affiliated with the unit in the current
dispatch location.
23. Press Back to return to the Trace Mode display.
24. Scroll down to highlight Band Info, and then press OK to view the Band Info display. This
screen displays the primary and secondary control channels: Pri Band: 02 for 800 MHz; Sec
Band: 02 for 800 MHz and 04 for 900 MHz.
25. Press Back to return to the Trace Mode display.
26. Scroll down to highlight Bandmap, and then press OK to view the Bandmap
display. This
screen displays the currently selected regional bandmap.
27. Press Back to return to the Trace Mode display.
