Motorola L6Q - Chapter 1: Charger Overview

Chapter 1
Charger Overview
Figure 1: Charger Overview
1
2
5
7
4
8
3
6
Table 1: Charger Overview
Label Description
1 LED Indicator
2 Charging Pocket
3 Male Connector
4 Male Connector Latch
5 Female Connector
6 Mounting Bracket Rails
7 Magnet
8 Rubber Foot
Table 2: Charger Specification
INPUT OUTPUT
15 V , 6 A (Up to 2 Multi-Unit Chargers) 4.35 V , 1.25 A x 6 pockets
MN010173A01-AA
Chapter 1: Charger Overview
7
