Motorola MC3000 Operating And Installation Manual

Installation
Setting DIP Switches
2-8 MC3000 Digital Deskset Operator and Installation Manual
(6880309L15-A)
Setting DIP Switches
The deskset must be opened for access to the DIP switches. You must remove power
prior to opening the deskset. The one DIP switch S46 is reserved for future use.
Back Panel Connector Layout
Table 2-3: DIP Switch Settings Table
Switch 4 Positions
* = Default
Function
S46 *OFF, ON Reserved for future use
*OFF, ON Reserved for future use
*OFF, ON Reserved for future use
*OFF, ON Reserved for future use
Figure 2-7: MC3000 Deskset - Back panel
