5-50 Disassembly/Reassembly Procedures Radio Exploded Mechanical Views and Parts Lists
* For defective main boards, customers must order Back Kit.
** For 300/350 MHz only
DP4400e Nameplate 33012015052
DP4401e Nameplate 33012015053
DP4600e Nameplate 33012015054
DP4601e Nameplate 33012015055
DP4800e Nameplate 33012015056
DP4801e Nameplate 33012015057
Antenna ID
Band
Antenna ID band (Grey-10pcs) 32012244001
Antenna ID band (Yellow-10pcs) 32012244002
Antenna ID band (Green-10pcs) 32012244003
Antenna ID band (Blue-10pcs) 32012244004
Antenna ID band (Purple-10pcs) 32012244005
Battery
IMPRES Li-Ion TIA4950 HAZLOC IP68 2900T LV PMNN4489_
Standard NiMH 1300 mAh IP67 1400T PMNN4412_
IMPRES Li-Ion Slim 1500 mAh PMNN4407_
IMPRES Hi-Cap Li-Ion Non-FM 2150 mAh PMNN4409_
Core Slim Li-Ion 1500 mAh PMNN4406_
IMPRES FM Li-Ion 2300 mAh 2350T NNTN8129_
IMPRES Li-Ion 2300 mAh 2350T PMNN4424_R**
IMPRES IP67 Li-Ion 2700 mAh 2800T PMNN4448_R
Li-Ion IP57 2000 mAh PMNN4463_
Li-Mn 1400 mAh low temp -30C battery Submersible
(IP57)
PMNN4435_R
IMPRES Slim Li-Ion IP68 2100T PMNN4491_
IMPRES Li-Ion IP68 3000T LV PMNN4493_
IMPRES Li-Ion VIB IP68 3000T LV PMNN4488_
Belt Clips
Belt Clip 2” PMLN4651_
Belt Clip 2.5" PMLN7008_
Vibrating Belt Clip 2.5” PMLN7296_
GNSS Antenna
Antenna, Chip, GLONASS BT/GPS Antenna Module AN000151A01
Table 5-6. Additional Part List Table (Continued)
Item Description Part Number
