2-2 Test Equipment and Service Aids Service Aids
2.2 Service Aids
Table 2-2 lists the service aids recommended for working on the radio. While all of these items are
available from Motorola, most are standard workshop equipment items, and any equivalent item
capable of the same performance may be substituted for the item listed.
* Earlier versions of programming cables will not work with the radio.
Table 2-2. Service Aids
Motorola
Part No.
Description Application
RLN4460_ Portable Test Set Enables connection to the audio/accessory jack.
Allows switching for radio testing.
GMVN5141_ Customer Programming
Software on CD-ROM
Allows servicer to program radio parameters, tune
and troubleshoot radios.
PMKN4012B* Portable Programming Cable This cable connects the radio to a USB port for radio
programming and data applications.
PMKN4013C* Portable Programming, Testing &
Alignment Cable
This cable connects the radio to a USB port for radio
programming, testing and alignment.
PMNN4428_ 7.5V Universal Battery Eliminator Connects to radio via battery eliminator cable.
PMLN6154_ RF Adaptor Adapts radio’s antenna port to SMA cabling of test
equipment.
PMLN6422_ RF Cable This cable measures RF related measurements.
TL000015A01 Chassis and Knob Opener Enables the removal of chassis from radio housing.
PMLN6155_ RF Adaptor Holder Holds RF connector to radio.
NLN9839_ Vacuum Pump Kit Allows servicer to test for leakages.
NTN4265_ Pressure Pump Kit Allows servicer to locate leakages.
5871134M01 Connector Fitting This connector allows the vacuum hose to be
connected to the radio chassis.
3271133M01 Fitting Seal This seal secures the connector fitting to the radio
chassis.
