3-6 Transceiver Performance Testing Display Model Test Mode
Table 3-5. Test Frequencies
Channel
Selector
Switch
Position
Test
Channel
UHF VHF
300
MHz
Band
350
MHz
Band
1 Low Power
9 High Power
TX#1 or #9
RX#1 or #9
403.15
403.15
136.075
136.075
300.025
300.025
350.025
350.025
2 Low Power
10 High Power
TX#2 or #10
RX#2 or #10
423.25
423.25
142.575
142.575
308.525
308.525
357.525
357.525
3 Low Power
11 High Power
TX#3 or #11
RX#3 or #11
444.35
444.35
146.575
146.575
317.025
317.025
364.525
364.525
4 Low Power
12 High Power
TX#4 or #12
RX#4 or #12
465.45
465.45
155.575
155.575
325.525
325.525
371.525
371.525
5 Low Power
13 High Power
TX#5 or #13
RX#5 or #13
485.55
485.55
161.575
161.575
334.025
334.025
378.525
378.525
6 Low Power
14 High Power
TX#6 or #14
RX#6 or #14
506.65
506.65
167.575
167.575
342.525
342.525
385.525
385.525
7 Low Power
15 High Power
TX#7 or #15
RX#7 or #15
526.75
526.75
173.975
173.975
351.025
351.025
392.525
392.525
8 Low Power
16 High Power
TX#8 or #16
RX#8 or #16
527.00
527.00
174.000
174.000
359.925
359.925
399.925
399.925
