Disassembly/Reassembly Procedures Radio Exploded Mechanical Views and Parts Lists 5-43
Table 5-4. Limited Keypad Model Exploded View Parts List
Item Description Part Number
1 Antenna See Chapter 1.4: Model
Charts
2 Front Kit Assembly See Table 5-6. Additional
Part List Table
2.01 Front Housing Assembly See Table 5-6. Additional
Part List Table
2.02 Emergency Button 38012008001
2.03 UC Escutcheon 13012035001
2.04 Mic Membrane With Stiffener SL000209A01
2.05 Boot, Microphone SL000208A01
2.06 Beidou/GLONASS Antenna See Table 5-6. Additional
Part List Table
2.07 Screw Shoulder, M1.2 X 3.2MM 0371160D01
2.08 Speaker Mesh SL000217A01
2.09 Speaker AC000028A02
2.10 UC Flex PF000917A01
2.11 Interface Flex PF000915A01
2.12 Keypad Flex See Table 5-6. Additional
Part List Table
2.13 Speaker Retainer- Grounding Contact Assembly 0104068J82
2.14 Screw, Thread Forming 0386434Z02
2.15 Front Dampener, Color Display 75012070001
2.16 Display Side Padding 75012137001
2.17 Display Module 72012010004
2.18 Back Dampener, Color Display HW000613A01
2.19 Microphone 50012012003
2.20 Keypad Controller (LKP) 0104070J41
2.21 Interface Board 0104065J48
2.22 Screw, Keypad Retainer 0378212A04
2.23 Front Nameplate 33012037001
2.24 Conductive Pad 75012224001
3 Back Cover Kit Assembly See Table 5-6. Additional
Part List Table
