MAINTENANCE 6 - 21
EXPLODED VIEWS & PARTS LISTS
Transceiver – Exploded View and Parts List
Figure 6-14 Transceiver Exploded View
NOTE:
For optimum performance, all replacement parts, diodes, transistors and integrated circuits
must be ordered by Motorola part numbers.
NOTE:
Terminals with special label OPTION BOARD MOUNTED (see dotted lines on figure above)
are equipped with an additional board inside the transceiver cover plate.
Refer to the figure next page before disassembling such terminals.
11
12
14
9
10
2
3
4
5
8
13
6
1
17b
17a
7
17c
17d
18
15
16
To Next Page
