Motorola Pro Series Elite - Page 102

VHF Circuit Board/ Schematic Diagrams and Parts List 6-11
Q3561 4813824A17 PNP
Q3721 4802245J50 UMC5N
Q3801 4813827A07 MMBR943
Q400 4809579E18 MOSFET P-CHAN
Q403 4813824A17 TSTR MMBT3906
Q405 4802245J54 Dual NPN
Q410 4802245J54 Dual NPN
Q417 4802245J50 Dual NPN/PNP
Q502 5180159R01 Dual NPN
Q505 4880214G02 NPN
R3200 0662057M54 150
R3201 0662057M82 2.2K
R3202 0662057M90 4.7K
R3203 0662057M98 10K
R3204 0662057M26 10
R3205 0662057M74 1K
R3206 0662057N23 100K
R3207 0662057N13 39K
R3208 0662057M50 100
R3209 0662057M74 1K
R3210 0662057M82 2.2K
R3211 0662057M82 2.2K
R3212 0662057M90 4.7K
R3213 0662057M82 2.2K
R3214 0662057M34 22
R3219 0662057M50 100
R3220 0662057M90 4.7K
R3221 0662057M50 100
R3224 0662057M26 10
R3225 0662057M74 1K
R3226 0662057M26 10
R3270 0662057M74 1K
R3271 0662057M42 47
R3272 0662057N15 47K
R3273 0662057N15 47K
R3274 0662057M83 2.4K
R3275 0662057M74 1K
R3276 0662057N30 200K
R3303 0662057N23 100K
R3304 0662057N23 100K
R3305 0662057N19 68K
R3306 0662057M82 2.2K
R3307 0662057N11 33K
R3308 0662057M78 1.5K
R3309 0662057M92 5.6K
R3310 0662057M98 10K
R3311 0662057M26 10
R3312 0662057M38 33
R3313 0662057M34 22
R3314 0662057M26 10
R3315 0662057M62 330
Circuit
Ref
Motorola
Part No.
Description
R3316 0662057M66 470
R3317 0662057N23 100K
R3318 0662057M66 470
R3321 0662057M54 150
R3322 0662057M58 220
R3323 0662057M32 18
R3324 0662057M58 220
R3501 0662057M61 300
R3502 0662057M32 18
R3503 0662057M61 300
R3505 0662057M62 330
R3512 0662057A27 120
R3513 0662057A25 100
R3519 0680539Z01 0.1
R3542 0662057M92 5.6K
R3543 0662057M50 100
R3544 0662057A25 100
R3545 0662057A25 100
R3546 0662057N11 33K
R3547 0662057N01 12K
R3548 0662057M95 7.5K
R3551 0662057M40 39
R3561 0662057N01 12K
R3562 0662057N11 33K
R3563 0662057N33 270K
R3564 0662057N35 330K
R3569 0662057M92 5.6K
R3570 0662057M98 10K
R3571 0662057A27 120
R3572 0662057A27 120
R3573 0662057A27 120
R3701 0662057M50 100
R3703 0662057M54 150
R3704 0662057M54 150
R3705 0662057N11 33K
R3721 0662057M66 470
R3722 0662057M74 1K
R3723 0662057M50 100
R3727 0662057N23 100K
R3741 0662057M50 100
R3751 0662057N30 200K
R3752 0662057N35 330K
R3761 0662057N15 47K
R3802 0662057M50 100
R3803 0662057M58 220
R3804 0662057M98 10K
R3805 0662057N08 24K
R3806 0662057M34 22
R3808 0662057M26 10
R3811 0662057M50 100
R3816 0662057M74 1K
Circuit
Ref
Motorola
Part No.
Description
R3817 0662057M01 0
R3821 0662057M58 220
R3822 0662057M42 47
R3823 0662057N11 33K
R3824 0662057N07 22K
R3825 0662057M38 33
R3826 0662057M32 18
R3828 0662057M50 100
R3829 0662057M01 0
R3831 0662057M98 10K
R3832 0662057N01 12K
R3833 0662057M58 220
R3834 0662057M42 47
R3835 0662057N15 47K
R3836 0662057M98 10K
R400 0662057N15 47K
R406 0662057N20 75K
R409 0662057M98 10K
R410 0662057N23 100K
R411 0662057M98 10K
R413 0662057M01 0
R414 0662057V34 180K
R415 0662057V26 91K
R416 0662057N13 39K
R418 0662057M01 0
R421 0662057M81 2K
R423 0662057N39 470K
R424 0662057N12 36K
R425 0662057N10 30K
R427 0662057M84 2.7K
R428 0662057M10 2.2
R429 0662057M98 10K
R431 0662057N39 470K
R432 0662057N16 51K
R434 0662057M62 330
R435 0662057M81 2K
R436 0662057M01 0
R445 0662057N08 24K
R446 0662057N31 220K
R447 0662057N51 1.5MEG
R448 0662057N33 270K
R449 0662057N08 24K
R450 0683962T45 68,1 W
R451 0662057N03 15K 5%
R457 0662057M98 10K
R460 0662057M90 4.7K
R463 0662057M61 300
R471 0662057M92 5.6K
R472 0662057N12 36K
R473 0662057M26 10
R475 0662057M01 0
Circuit
Ref
Motorola
Part No.
Description
R476 0662057N08 24K
R477 0662057M74 1K
R478 0662057M98 10K
R481 0662057N08 24K
R492 0662057M01 0
R498 0662057M98 10K
R499 0662057M98 10K
R501 0662057M70 680
R502 0662057M56 180
R505 0662057M98 10K
R506 0662057N15 47K
R702 0662057M01 0
RT400 0680590Z01 Thermistor 33K
S501 4080710Z01
4080710Z02
Channel Switch
**Frequency Switch
S502 1880619Z02 Volume Switch
SH3201 2602023X08 SHIELD
SH3202 2686081B02 SHIELD
SH3203 2686081B03 SHIELD
SH3301 2686081B01 SHIELD
SH3302 2686081B05 SHIELD
SH3303 2686081B06 SHIELD
SH3501 2686081B03 SHIELD
SH3502 2686081B04 SHIELD
SH3701 2680511Z01 SHIELD
SH3702 2680511Z01 SHIELD
SH3801 2680513Z01 SHIELD
SH3802 2680514Z01 SHIELD
SH400 2602001P16 Aoba Ctrl Shield
T3301 2580541Z02 XFMR Coil
T3302 2580541Z02 XFMR Coil
U3201 5102463J58 LP2980
U3220 5109632D83 LVZIF
U3501 5185130C65 LDMOS Driver
U3502 5185765B28 PCIC
U3503 5185963A15 Temperature Sense
U3701 5185963A27 LVFR ACN
U3711 5105739X05 Regulator Linear
U3801 5105750U54 VCO IC
U3802 2113743L17 1000pF
U400 5102463J40 3.3V Reg
U404 5185130C53 Asfic Cmp
U406 5102463J59 Flash Rom 256K
U407 5102463J62 EEPROM 16Kx8
U409 5102226J56 uP HC11FLO
U420 5102463J44 Audio Pa
VR432 4805656W08 5.6V Zener
VR433 4805656W08 5.6V Zener
VR439 4880140L17 12V Zener
VR445 4880140L15 10V ZENER
VR446 4880140L15 10V ZENER
Circuit
Ref
Motorola
Part No.
Description
