Motorola Pro Series Elite - UHF Band 1, Circuit Board; Schematic Diagrams and Parts List (PCB No. 8471441 L01)

UHF Band 1, Circuit Board/ Schematic Diagrams and Parts List (PCB No. 8471441L01) 7-21
C279 2113946N03 CAP CER CHP 2.2UF 16V
C281 2113944A40 CAP CER CHP 100.0PF 50V
5%
C285 2113944A40 CAP CER CHP 100.0PF 50V
5%
C286 2113946K02 CAP CER CHP 0.10UF 16V
C289 2113944A40 CAP CER CHP 100.0PF 50V
5%
C291 2313960M51 CAP,FXD,10UF,+10%,-
10%,6.3V-DC
C292 2113946K02 CAP CER CHP 0.10UF 16V
C293 2113945G98 CAP,FXD,.47UF,+10%,-
10%,50V-DC
C294 2113944A40 CAP CER CHP 100.0PF 50V
5%
C295 2113944A40 CAP CER CHP 100.0PF 50V
5%
C296 2113946K02 CAP CER CHP 0.10UF 16V
C297 2113945B02 CAP CER CHP 10,000PF 25V
10%
C298 2113946K02 CAP CER CHP 0.10UF 16V
C301 2113944A14 CAP CER CHP 3.6PF 50V +/-
0.25
C302 2113944A25 CAP CER CHP 10.0PF 50V +/
- 0.5
C303 2113944C20 CAP CER CHP 3.9PF 50V +/-
0.25
C304 2113944A25 CAP CER CHP 10.0PF 50V +/
- 0.5
C305 2113944A80 CAP,FXD,20PF,+5%,-5%,50V-
DC,04
C306 NOTPLACED GCAM DUMMY PART
NUMBER
C307 2113944A40 CAP CER CHP 100.0PF 50V
5%
C308 2113944A40 CAP CER CHP 100.0PF 50V
5%
C309 2113944A40 CAP CER CHP 100.0PF 50V
5%
C310 2113944A40 CAP CER CHP 100.0PF 50V
5%
C311 NOTPLACED GCAM DUMMY PART
NUMBER
C312 2113944A24 CAP CER CHP 9.1PF 50V +/-
0.5P
C313 2113944A25 CAP CER CHP 10.0PF 50V +/
- 0.5
C314 2113946K02 CAP CER CHP 0.10UF 16V
C315 2113944A40 CAP CER CHP 100.0PF 50V
5%
Circuit
Ref
Motorola
Part No.
Description
C316 2113944C20 CAP CER CHP 3.9PF 50V +/-
0.25
C317 2113944A24 CAP CER CHP 9.1PF 50V +/-
0.5P
C318 2113944A22 CAP CER CHP 7.5PF 50V +/-
0.5P
C319 2113944A11 CAP CER CHP 2.7PF 50V +/-
0.25
C320 2113944A79 CAP,FXD,16PF,+5%,-5%,50V-
DC,04
C321 2113944A40 CAP CER CHP 100.0PF 50V
5%
C322 2113944A38 CAP CER CHP 82.0PF 50V
5%
C324 2113944A29 CAP CER CHP 22.0PF 50V
5%
C325 2115153H26 CAP, CERAMIC, COG
C326 2113946K02 CAP CER CHP 0.10UF 16V
C327 2113946K02 CAP CER CHP 0.10UF 16V
C328 2113946K02 CAP CER CHP 0.10UF 16V
C329 2113946K02 CAP CER CHP 0.10UF 16V
C334 2113945A13 CAP CER CHP 4700PF 50V
10%
C337 NOTPLACED GCAM DUMMY PART
NUMBER
C338 NOTPLACED GCAM DUMMY PART
NUMBER
C343 2113946K02 CAP CER CHP 0.10UF 16V
C344 2113945D04 CAP CER CHP 100,000PF
25V 10%
C345 2113946K02 CAP CER CHP 0.10UF 16V
C346 2113946K02 CAP CER CHP 0.10UF 16V
C347 2113946K02 CAP CER CHP 0.10UF 16V
C348 2113946K02 CAP CER CHP 0.10UF 16V
C349 2113945D04 CAP CER CHP 100,000PF
25V 10%
C350 2113946K02 CAP CER CHP 0.10UF 16V
C351 2113944A41 CAP CER CHP 120.0PF 50V
5%
C352 2113946K02 CAP CER CHP 0.10UF 16V
C355 2113946K02 CAP CER CHP 0.10UF 16V
C357 2113946K02 CAP CER CHP 0.10UF 16V
C358 NOTPLACED GCAM DUMMY PART
NUMBER
C359 NOTPLACED GCAM DUMMY PART
NUMBER
C360 2113944A13 CAP CER CHP 3.3PF 50V +/-
0.25
C361 2113946K02 CAP CER CHP 0.10UF 16V
C362 2113946K02 CAP CER CHP 0.10UF 16V
Circuit
Ref
Motorola
Part No.
Description
C364 2113944A81 CAP,FXD,24PF,+5%,-5%,50V-
DC,04
C366 NOTPLACED GCAM DUMMY PART
NUMBER
C367 2113944A82 CAP,FXD,30PF,+5%,-5%,50V-
DC,04
C370 2113944A17 CAP CER CHP 4.7PF 50V +/-
0.25
C371 NOTPLACED GCAM DUMMY PART
NUMBER
C372 2113944A40 CAP CER CHP 100.0PF 50V
5%
C373 NOTPLACED GCAM DUMMY PART
NUMBER
C374 2113944A40 CAP CER CHP 100.0PF 50V
5%
C375 2113944A40 CAP CER CHP 100.0PF 50V
5%
C378 NOTPLACED GCAM DUMMY PART
NUMBER
C380 2113945B02 CAP CER CHP 10,000PF 25V
10%
C381 NOTPLACED GCAM DUMMY PART
NUMBER
C382 2313960B57 CAP,FXD,10UF,+10%,-
10%,6.3V-DC
C383 NOTPLACED GCAM DUMMY PART
NUMBER
C385 2113944A82 CAP,FXD,30PF,+5%,-5%,50V-
DC,04
C386 2113944A40 CAP CER CHP 100.0PF 50V
5%
C390 NOTPLACED GCAM DUMMY PART
NUMBER
C391 2113944A81 CAP,FXD,24PF,+5%,-5%,50V-
DC,04
C502 2313960A55 CAP,FXD,.47UF,+10%,-
10%,25V-DC
C503 2113944A84 CAP,FXD,43PF,+5%,-5%,50V-
DC,04
C505 2113944A40 CAP CER CHP 100.0PF 50V
5%
C511 2113944A40 CAP CER CHP 100.0PF 50V
5%
C512 2113944A40 CAP CER CHP 100.0PF 50V
5%
C513 2113944A40 CAP CER CHP 100.0PF 50V
5%
C514 2113944A40 CAP CER CHP 100.0PF 50V
5%
Circuit
Ref
Motorola
Part No.
Description
C520 2113945B02 CAP CER CHP 10,000PF 25V
10%
C521 2113945B02 CAP CER CHP 10,000PF 25V
10%
C522 2113945B02 CAP CER CHP 10,000PF 25V
10%
C523 2113945B02 CAP CER CHP 10,000PF 25V
10%
C525 2113944A40 CAP CER CHP 100.0PF 50V
5%
C526 2113944A40 CAP CER CHP 100.0PF 50V
5%
C527 2113944A40 CAP CER CHP 100.0PF 50V
5%
C528 2113944A40 CAP CER CHP 100.0PF 50V
5%
C529 2113944A40 CAP CER CHP 100.0PF 50V
5%
C530 2113944A40 CAP CER CHP 100.0PF 50V
5%
C531 2113944A40 CAP CER CHP 100.0PF 50V
5%
C532 2113944A40 CAP CER CHP 100.0PF 50V
5%
C533 2113944A40 CAP CER CHP 100.0PF 50V
5%
C534 2113944A40 CAP CER CHP 100.0PF 50V
5%
C535 2113944A40 CAP CER CHP 100.0PF 50V
5%
C536 2113944A40 CAP CER CHP 100.0PF 50V
5%
C537 2113944A40 CAP CER CHP 100.0PF 50V
5%
C538 2113944A40 CAP CER CHP 100.0PF 50V
5%
C539 NOTPLACED GCAM DUMMY PART
NUMBER
C540 NOTPLACED GCAM DUMMY PART
NUMBER
C541 NOTPLACED GCAM DUMMY PART
NUMBER
C542 NOTPLACED GCAM DUMMY PART
NUMBER
C543 NOTPLACED GCAM DUMMY PART
NUMBER
C544 2113944A40 CAP CER CHP 100.0PF 50V
5%
C545 2113944A40 CAP CER CHP 100.0PF 50V
5%
Circuit
Ref
Motorola
Part No.
Description
