Hardware Setup
18
4.6 Supplying Power to the RFS6000 Series RF Switch
1. Plug an approved AC power cord into the power connector at the back of the RFS6000 Series RF
Switch.
2. Plug the cord into a standard AC outlet with a voltage range of 100 to 240 VAC.
.
WARNING! An improper shutdown can render the RFS6000 Series RF Switch
inoperable such that it could require service by Motorola Support. Do not
remove AC power without first following the shutdown procedure. An
abrupt loss of power can corrupt the information stored on the device.
Rack mount
bracket
AC inlet
