2-2 Overview
MB*/* Installation and Operation Manual
Configuration
The MB*/* is fully configured in the factory per customer request. It is recommended that you
verify the configuration listed on the outside of the shipping carton with the configuration that
you ordered. The shipped configuration is also noted in a label on the side of the electronics
chassis and the housing.
Figure 2-2 illustrates the MB*/* configuration notation:
Figure 2-2
MB*/* configurator
MB
/
Key
X
S
Overcurrent Protection
Shunt
20A Auto Fuse
Key
X
B
N
Housing Size
By-Pass
None (Electronics Only)
Standard
Key
X
L
H
Return Amp w/JXP-ZX
Low Gain Hybrid
High Gain Hybrid
No Return
Key
X
T
A
B
C
D
E
F
Level Control
None
TDU
ADU 499.25/S
ADU 439.25/S
ADU 403.25/S
ADU 445.25/S
ADU 549.00/S
ADU 325.25/S
Key
X
G
Hybrid Technology
Standard (High Gain Silicon)
E-GaAs (High Output, High Gain)
Key
X
C
S
P
Housing Finish
Chromate
Chromate w/SS plugs
Epoxy
Standard
Key
X
C
Voltage Surge Protector
FTEC; Crowbar
Surge Arrestor
Key
X
L
AC Current Capability
Low Current (10 Amp) - Available
for electronics package only
Standard (15 Amp)
Key
X
N
Power Supply
Non-power
Factor Correction
Power Factor
Correction (Standard)
Key
X
S
RF Configurations
Dual Output
Single Output
Key
B
X
Ingress switching
None
Ingress Control Switches
Key
X
S
Status Monitoring
LL-MB-F3
None
Key
X
P
Special Options
None
34 dB Gain Option
Key
X
Reserved
Reserved
Key
X
Reserved
Reserved
Key
E
Reserved
Ergonomics
Key
75E
75S
75K
75J
75A
75M
87E
87S
87K
87J
87A
87M
Frequency Range
5-30 MHz, 47-750 MHz
5-40 MHz, 52-750 MHz
5-42 MHz, 54-750 MHz
5-55 MHz, 70-750 MHz
5-65 MHz, 85-750 MHz
5-80 MHz, 108-750 MHz
5-30 MHz, 47-870 MHz
5-40 MHz, 52-870 MHz
5-42 MHz, 54-870 MHz
5-55 MHz, 70-870 MHz
5-65 MHz, 85-870 MHz
5-80 MHz, 108-870 MHz
Key
X
A
B
C
D
Station Slope
S,K,E splits: 10 [Fmin-750 MHz], 12 [Fmin-870 MHz]
A split: 9 [Fmin-750 MHz], 10 [Fmin-870 MHz]
J split: 9.5 [Fmin-750 MHz], 11.5 [Fmin-870 MHz]
S,K,E splits: 12 [Fmin-750 MHz]
S,K,E splits: 14 [Fmin-750 MHz, 870 MHz]
6 [Fmin-750 MHz, 870 MHz]
8 [Fmin-750 MHz, 870 MHz]
