Housing
The MB*/* is furnished in an MB-HSG aluminum housing that protects the electronics from
weather and dissipates internally generated heat.
Figure 2-3 illustrates a top view of the MB-HSG housing and provides its dimensions:
Figure 2-3
MB-HSG dimensions — top view
15.4
9.6
Figure 2-4 illustrates a side view of the MB-HSG and provides its dimensions:
Figure 2-4
MB-HSG dimensions — side view
5.6
Messenger clamp bolts
