6809505A63-O September 26, 2006 5
Level 1 and 2 Service Manual
Specifications
General Function Specification
Frequency Range GSM 900
TX: 880 - 915 MHz
Frequency (MHz) = 890 + (0.2 × n) where: 0 <
n < 124
Frequency (MHz) = 890 + (0.2 × (n – 1024)) where: 955 <
n < 1023
RX: 925 – 960 MHz
Frequency (MHz) = 935 + (0.2 × n) where: 0 < n < 124
Frequency (MHz) = 935 + (0.2 × (n – 1024)) where: 955 < n < 1023
Frequency Range DCS 1800
TX: 1710 to 1785 MHz
Frequency (MHz) = 1710.2 + (0.2 × (n – 512)) where: 512 <
n < 885
RX: 1805.2 to 1879.8 MHz
Frequency (MHz) = 1805.2 + (0.2 × (n – 512)) where: 512 < n < 885
Frequency Range PCS 1900
TX: 1850 to 1910 MHz
Frequency (MHz) = 1850.2 + (0.2 × (n – 512)) where: 512 < n < 810
RX: 1930 to 1990 MHz
Frequency (MHz) = 1930.2 + (0.2 × (n – 512)) where: 512 < n < 810
Frequency Range WCDMA 2100
TX: 1920 to 1980 MHz
Frequency (MHz) = UARFCN
1
÷ 5, where: 9612 < UARFCN
1
< 9888UARFCN
1
in increments
of 25
RX: 2110 to 2170 MHz
Frequency (MHz) = UARFCN
1
÷ 5, where: 10562 < UARFCN
1
< 10838UARFCN
1
in
increments of 25
Channel Spacing 200 kHz (GSM, DCS, PCS), 5 MHz UMTS
Channels 174 EGSM, 374 DCS, 274 PCS carriers with 8 channels per carrier, 11 UMTS
Modulation GMSK AT BT = 0.3 (GSM, DCS, PCS), QPSK (UMTS)
Transmitter Phase Accuracy 5 degrees RMS, 20 Degrees peak
Duplex Spacing 45 MHz GSM, 95 MHz DCS, 80 MHz PCS, 190 MHz UMTS
Frequency Error ± 0.10 ppm
Input/Output Impedance 50 ohms (nominal)
Operating Voltage +3.6V dc to +
10% (battery)
+4.4V dc to +10% (external connector)
Transmit Current Drain 101-260 mA average talk current drain
Stand-by Current drain 5 mA (DRX2), 2 mA (DXR9) typical
Temperature Range -10° C to +55° C (+15° F to +130° F)
Dimensions, with 940 mAh Li Ion battery 53 mm x 103 mm x 15 mm
(2.09 inches x 4.06 inches x 0.59 inches)
Size (Volume) 80 cc (4.88 in
3
), with battery
Weight 100 grams (3.53 oz), with battery
Battery Life, with standard 940 mAh
Li-Ion Battery
WCDMA
Voice Call = 205mins
P2P Call = 120 mins
Standby = 375 hrs
GSM
Voice Call - 255 mins
Standby DRx5 = 375 hrs
All talk and standby times are approximate and depend on network configuration, signal
strength, and features selected. Standby times are quoted at DRX=5.
Talk times are quoted with DTX on.
Battery Charge Time 4 hours to 90% of 940 mAh capacity
Alert volume Max 95 dB @5cm, 0.5 Watts input
