16 VC70 Vehicle Computer
7. Plug the keyboard cable into one of the USB connectors and carefully
tighten the thumbscrews.
Installing an Optional VC5090 Keyboard on VC70
You can install the VC5090 keyboard on the VC70 using the keyboard
adapter kit (PN KT-VC50KYBD-ADPT-R).
The kit contains the following items:
• Two spacers with screws and washers
• Adapter cable
1. Attach the keyboard spacers to both sides of the VC70 using 2
M5x14mm Torx head screws with captive washers for each spacer.
Tork the screws to 20 + 5% kgf-cm (17 + 5% lbs-in).
CAUTION Do not use tools to secure connector thumbscrews. Only
tighten thumbscrews by hand.
NOTE When using the VC5090 keyboards, the integrated keyboard
heater is not supported.
