Quick Reference Guide 19
3. Attach the numeric keyboard mount to the VC70, using four
M5x14mm Torx head screws with captive washers.Tighten the
screws.
4. Torque the numeric keyboard Torx head screws to 20 + 10% kgf-cm
(17 + 10% lbs-in).
6 Torx Head Screws
with captive washers
Numeric Keyboard
Numeric Keyboard Mount
