8 Settings via the MICT
152 Rev. 03/2019
– Analog Current Input
Simulation of the analog current input
– Control button for adjustments between the configured values (e.g. 0 mA and 20 mA)
– Field for manual input of the desired value in mA
– Displays the value in °crankshaft by which the timing is offset
– Analog Voltage Input
Simulation of the analog voltage input
– Control button for adjustments between the configured values (e.g. 0 V and 10 V)
– Field for manual input of the desired value in V
– Displays the value in °crankshaft by which the timing is offset
– Schedule A/B
Select between Schedule A and B
– Timing Point
Displays the global ignition timing as it changes during the simulation.
While connected to the device, the ignition timing is simulated depending on the actual engine
speed and marked as
in the diagram.
