Warning. Read the instructions before
operating the machine.
Danger! Risk of thrown objects. Keep
all persons away from the work area whilst
working.
Only for lawn mowers with thermal engine.
Only for electric lawn mowers with mains
power supply.
Only for electric lawn mowers with mains
power supply.
Danger! Danger of cutting. Cutting
means in motion. Do not insert hands or
feet into the cutting means housing.
Be careful when using the sharp cutting
means. Do not put hands or feet near or
under the opening of the cutting means. The
cutting means continues to turn even after
the safety key (deactivation device) before
any maintenance is carried out.
IMPORTANT Any damaged or illegible decals must be
replaced. Order replacement decals from an Authorised
Service Centre.
3.3 IDENTIFICATION LABEL
1. Sound power level.
2. Conformity marking.
3.
4. Type of machine.
5. Serial number.
6. Name and address of Manufacturer.
7. Article code.
8. Max. motor operation speed.
9. Weight in kg.
10. Power voltage and frequency.
11. Electrical protection rating.
12. Nominal power.
space on the label on the back of the cover page.
IMPORTANT Quote the information on the product iden-
tication label whenever you contact an Authorised Service
Centre.
IMPORTANT The example of the Declaration of Con-
formity is provided on the last pages of the manual.
3.4 MAIN COMPONENTS
The machine is composed of a series of main components
that have the following functions (Fig.1.0):
A. Chassis: this is the casing that houses the rotating
cutting means.
B. The engine: drives both the cutting means and the
wheel traction (if available).
C. Cutting means: the element designed to cut the
grass.
D. Rear discharge guard: it is a safety device which
prevents objects collected by the cutting means
from being projected away from the machine.
E. Side discharge guard (if available): it is a safety
device which prevents objects collected by the
cutting means from being projected away from the
machine.
F. Side discharge chute (if available): apart from
objects collected by the cutting means from being
projected away from the machine.
G. Grass catcher: apart from collecting the mown
cutting means from being projected away from the
machine.
H. Handle: this is the operator’s work station. It is
long enough to ensure the operator remains at a
safe distance from the rotary cutting means whilst
working.
I. Battery
chapter 13 “attachments on request”): provides
manual.
J. Operator presence lever: this lever enables
the cutting means and drive to be operated. The
engine stops automatically when the lever is re-
leased.
K. Drive engagement lever (if available): this lever
engages the drive to the wheels and allows the
machine to move forward.
L. Hatch for accessing the battery compartment
M. Safety key (Deactivation device): The key ena-
bles / disables the machine electric circuit.
N. Battery charger (if it is not supplied with the ma-
device used to recharge the battery.
Strictly observe the indications and the safety reg-
ulations described in chap. 2.
4. ASSEMBLY
Certain components of the machine are not installed in the
-
ing the instructions below.
Unpacking and completing the assembly should be
performed on a at and stable surface, with enough space
for handling the machine and its packaging.. Do not use the
machine until all the indications provided in the “ASSEMBLY”
section have been carried out.
4.1 UNPACKING
1.
lose components.
2.
instructions.
3. Remove all the unassembled parts from the box.
