UNIT DESCRIPTION AND FUNCTION
FRONT
Air outlet
Left/right air direction
control tab
Caster
Up/down air louver
Handle
Note: Open the up/down air louver to the highest position before the unit is turned on.
Control panel
Left/right air swinging fins
BACK
Air-return grill
Power cord holders
Base stopper
Air inlet
Exhaust air outlet
