Mowox PM 4030 P User Manual

10 (EN)
Model
PM 5175 S
(DYM1668EC)
PM 5175 SHW
(DYM1666E3Q)
PM 5690 SHW
(DYM1669EQ)
PM 5690 SZT
(DYM1679B)
Engine Type
DG 750
DG 900
Engine design
4-stroke engine, overhead valve, 1 cylinder
Displacement; bore × stroke
171 cm
3
; 67 × 48 mm
196 cm
3
; 70 × 51 mm
Maximum power/ 3600 min
-1
3.0 kW (4.0 HP)
4.0 kW (5.4 HP)
Nominal power
2.6 kW (3.5 HP)
3.3 kW (4.4 HP)
Fixed speed
2800 min
-1
Maximal torque
9.0 Nm/2800 min
-1
10.5 Nm/2800 min
-1
Valve clearance (cold)
0.10 - 0.15 mm
0.15 - 0.25 mm
PTO shaft rotation
clockwise
Ignition system
Transistor ignition
Ignition angle
16° ± 2°
26.5° ± 2°
Spark plug type
F6RTC
F7RTC
Spark plug electrode spacing
0.6 - 0.8 mm
Lubrication system
Immersion lubrication
Cooling system
Forced air cooling
Blade length
510 mm
560 mm
Blade part number
DAYE 2105200262[...]
DAYE 2105200257[...] or
21052003412000A
Required engine oil quantity
0.4 l
0.55 l
Capacity petrol tank
0.9 l
1.8 l
Grass bag capacity
60 l
70 l
Net weight
29.5 kg
32.1 kg
38.8 kg
42.2 kg
Cutting height adjustment
25 - 75mm, 10 positions
25 - 75mm, 7 posi-
tions
Measured sound pressure level
at the user's position (EN ISO
5395-1 Annex F & EN ISO 5395-
2, EN IS0 4871)
85.4 dB(A)
K = 3 dB(A)
85.4 dB(A)
K = 3 dB(A)
85.1 dB(A)
K = 3 dB(A)
84.8 dB(A)
K = 3 dB(A)
Measured sound power level
L
WA
96.3 dB(A)
K = 1.79 dB(A)
96.3 dB(A)
K = 1.79 dB(A)
96.2 dB(A)
K = 1.90 dB(A)
95.7 dB(A)
K = 2.01 dB(A)
Guaranteed sound power level
L
WA G
(2000/14/EC)
98 dB(A)
98 dB(A)
98 dB(A)
98 dB(A)
Vibration (EN ISO 5395-1 Annex
G & EN ISO 5395-2)
6.93 m/s²
K = 1.5 m/s²
6.93 m/s²
K = 1.5 m/s²
3.40 m/s²
K = 1.5 m/s²
3.76 m/s²
K = 1.5 m/s²
