Model
PM 4030 P
(DYM161702)
PM 4650 S
(DYM1666E)
PM 4650 SHW
(DYM1626ECQ)
PM 5165 SHW
(DYM1660E2Q)
Engine Type
DG 300
DG 500
DG 650
Engine design
4-stroke engine, overhead valve, 1 cylinder
Displacement; bore × stroke
80 cm
3
; 52 × 38 mm
135 cm
3
; 61 × 45 mm
149 cm
3
; 65 × 45
mm
Maximum power/ 3600 min
-1
1.4 kW (1.9 HP)
2.4 kW (3.2 HP)
2.7 kW (3.6 HP)
Nominal power
1.2 kW (1.6 HP)
1.9 kW (2.6 HP)
2.4 kW (3.2 HP)
Fixed speed
3000 min
-1
2800 min
-1
Maximal torque
3.6 Nm/,000 min
-1
6.6 Nm/2800 min
-1
7.5 Nm/2800 min
-1
Valve clearance (cold)
0.05 – 0.10 mm
0.10 - 0.15 mm
PTO shaft rotation
counterclockwise
clockwise
Ignition system
Transistor ignition
Ignition angle
22° ± 2°
16° ± 2°
Spark plug type
F7RTC
F6RTC
Spark plug electrode spacing
0.6 - 0.8 mm
Lubrication system
Immersion lubrication
Cooling system
Forced air cooling
Blade length
400 mm
460 mm
510 mm
Blade part number
DAYE 2105300136
DAYE 2105200263[…], 263002488,
21052003402000A or
2105200115C
DAYE
2105200262[...]
Required engine oil quantity
0.35 l
0.4 l
Capacity petrol tank
0.6 l
0.9 l
Grass bag capacity
50 l
60 l
Net weight
16.0 kg
26.6 kg
30.5 kg
31.4 kg
Cutting height adjustment
25 - 75mm, 6 posi-
tions
25 - 75mm, 10 positions
Measured sound pressure level
at the user's position (EN ISO
5395-1 Annex F & EN ISO 5395-
2, EN IS0 4871)
84.8 dB(A)
K = 3 dB(A)
82.9 dB(A)
K = 3 dB(A)
84.3 dB(A)
K = 3 dB(A)
86.1 dB(A)
K = 3 dB(A)
Measured sound power level
L
WA
94.3 dB(A)
K = 2.08 dB(A)
94.0 dB(A)
K = 1.88 dB(A)
94.2 dB(A)
K = 2.00 dB(A)
96.4 dB(A)
K = 1.83 dB(A)
Guaranteed sound power level
L
WA G
(2000/14/EC)
96 dB(A)
96 dB(A)
96 dB(A)
98 dB(A)
Vibration (EN ISO 5395-1 Annex
G & EN ISO 5395-2)
2.50 m/s²
K = 1.5 m/s²
2.40 m/s²
K = 1.5 m/s²
5.64 m/s²
K = 1.5 m/s²
7.60 m/s²
K = 1.5 m/s²
