Mowox PM 4030 P User Manual

25 (EN)
- Do not mow wet grass.
- Regularly clean the mulch insert, the inside of the case and the knife.
1. Lift the rear cover and remove the grass collection bag #5.
2. Slide the mulching insert #22 into the housing #9. Lock the mulching insert in the
opening of the mower housing with the button.
3. Carefully lower the rear cover.
6.10.2 Use with lateral ejection
Using the lateral ejection opening is the fastest of all ways of cutting grass. The grass
clippings are neither collected nor processed into mulch.
1. Unlock the side flap #13.
2. Attach the ejector wedge to the rotary axis of the cover.
3. Carefully lower the rear cover.
Before inserting the lateral ejection piece, perform the steps described in 6.10.1: Insert
the mulch add-on (22) into the rear opening.
1 2 3
1 2 3

Mowox PM 4030 P Specifications

General

Brand	Mowox
Model	PM 4030 P
Category	Lawn Mower
Language	English
