Moxa Technologies EtherDevice EDS-G205A-4PoE-1GSFP User Manual

- 13 -
Power
Input Voltage
12/24/48 VDC, redundant dual inputs
Operating Voltage
12 to 57 VDC
Rated Current
5.92 A @ 12 VDC
5.65 A @ 24 VDC
3.21 A @ 48 VDC
Power Consumption
11.73 W without PDs’ consumption
Inrush Current
17.4 A @ 24 VDC (0.1 to 1 ms)
Electrical Isolation
2250 VDC to chassis for 60 s
Heat Dissipation
36.4 BTU/h
Overload Current
Protection at Input
Present
Reverse Polarity
Protection
Present
Connection
2 removable 2-contact terminal blocks
Physical Characteristics
Housing
Aluminum, IP30 protection
Dimensions
29 x 135 x 105 mm
Weight
300 g
Installation
DIN-rail mounting,
Wall mounting (with optional kit)
Environmental Limits
Operating
Temperature
Standard models: 0 to 60°C (32 to 140°F)
Wide temp. models: -40 to 75°C (-40 to 167°F)
Storage Temperature
-40 to 85°C (-40 to 185°F)
Ambient Relative
Humidity
5 to 95% (non-condensing)
Standards and Certifications
Safety
UL 508
EMC
EN 55032/24
EMI
CISPR 32, FCC Part 15B Class A
EMS
IEC 61000-4-2 ESD: Contact: 6 kV; Air: 8 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 10 V/m
IEC 61000-4-4 EFT: Power: 2 kV; Signal: 2 kV
IEC 61000-4-5 Surge: Power: 2 kV; Signal: 2 kV
IEC 61000-4-6 CS: 10 V
IEC 61000-4-8
Rail Traffic
EN 50121-4
Shock
IEC 60068-2-27
Freefall
IEC 60068-2-32
Vibration
IEC 60068-2-6
WARRANTY
Time
5 years
Details
www.moxa.com/warranty
Patent http://www.moxa.com/doc/operations/Moxa_Patent_Marking.pdf
