Moxa Technologies NPort 5130A Quick Installation Guide

- 6 -
Specifications
Power Requirements
Power Input
12 to 48 VDC
Power Consumption NPort 5110A:
82.5 mA @ 12V, 47.3 mA @ 24V
NPort 5130A:
89.1 mA @ 12V, 49.5 mA @ 24V
NPort 5150A:
92.4 mA @ 12V, 52.8 mA @ 24V
Environmental Limits
Operating Temperature
Standard Models:
0 to 60°C (32 to 140°F)
Wide Temp. Models:
-40 to 75°C (-40 to 167°F)
Ambient Humidity
5 to 95% RH
Dimensions
With ears
75.2 x 80 x 22 mm (2.96 x 3.15 x 0.87 in)
Without ears
52 x 80 x 22 mm (2.05 x 3.15 x 0.89 in)
Protection
Serial Line Protection
Level 1 Surge, EN 61000-4-5
Magnetic Isolation
1.5 kV for Ethernet
Power Line Protection
Level 2 Burst (EFT), EN 61000-4-4
Level 3 Surge, EN 61000-4-5
Regulatory Approvals
FCC Class A, CE Class A, UL, LVD

Moxa Technologies NPort 5130A Specifications

General

Isolation	1.5 kV
Certification	CE, FCC
Serial interface type	RS-422, RS-485
Serial ports quantity	1
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols	ICMP, IP, TCP, UDP, DHCP, BOOTP, Telnet, DNS, HTTP, SMTP, IGMP v1/2
Compatible operating systems	SCO Unix, OpenServer UnixWare v2.1, v7 Unix SVR 4.2 Unix QNX 4.25, QNX 6 Solaris 10 FreeBSD AIX 5.x HP-UX 11i Mac OS v10.3 Linux v2.4.x, v2.6.x
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	5 - 95 %
Input voltage	12 - 48 V
Safety	UL, LVD

Weight and Dimensions

Weight	340 g
Dimensions (WxDxH)	52 x 80 x 22 mm
