5
Operating
Temperature
TCC-100/TCC-100I:
-20 to 60°C (-4 to 140 °F)
TCC-100-T/TCC-100I-T:
-40 to 85°C (-40 to 185 °F)
-40 to 85°C (-40 to 185°F)
External Power 12-48 VDC, terminal block
Protects against V+/V- reversal
Protects against 2 signals shorted together
Power Consumption TCC-100/TCC-100-T: 85 mA @ 12 V
TCC-100I/TCC-100I-T: 150 mA @ 12 V
Dimensions 67 × 100 × 22 mm (without ears)
90 × 100 × 22 mm (with ears)
Plug-In Screw
#22 to #16 AWG
CE, FCC (Class A), UL-60950-1
1.
This equipment is intended to be used in Restricted Access
Locations such as computer rooms for which access can
only be gained by SERVICE PERSONNEL or USERS who
have been instructed that the metal chassis of the
equipment is extremely hot. Access to the room must be
through the use of a key or security identity system.
2.
External metal parts of the equipment are hot!! Be sure to
protect your hands before touching the equipment.
